Cerberus Pyrotronics ZC Series Speaker Strobe Zone Cards 5030

ZC Series Speaker Non Coded N A C Circuit Cards ZC2 8B ZC2 4AB ZC3 4AB Limiting Option Modules PL864 25A PL864 70A PL864 25S AND ARCHITECT SPECIFICATIONS Fully Supervised Notification Appliances Speaker Strobe Non Coded Horns Chimes Style Y or Style Z Class A or B Fully Mappable and Controllable 70V or 25V Audio Signal Capability on Card ZC Cards are a series of optional MXLV modules provide various configurations of notification circuits such as speaker strobe non coded bells or chimes are versions of the ZC cards that allow the of single dual or three channel audio opera as well as Style Y or Style Z zone configuration All of the ZC cards can support either 25V or audio signals 24VDC polarity reversal type circuits also be used for strobe horn chime or bell appli ZC cards zones are individually fused but not limited When power limiting is required the card and appropriate PL864 modules must be to meet U L 864 power limiting requirements ZC cards plug into a slot in either the OMM 1 or cardcages Each ZC card occupies one of the available sub module addresses of the MXLV controller module The zones are completely and mappable using MXL AccuLINK software CSGM These outputs are fully and are controllable automatically through control by event logic or manually via the VSM 1 modules in the MXLV command console series cards may be used in non MXLV applications use as non coded NAC circuits 1 2 or 3 Audio Channel versions Plugs into OMM 1 or OMM 2 Cardcage Optional Power Limiting Modules U L 864 Listed U L C Listed equipment is approved for operation over the range of 0 to 49 1 Channel audio 25V or 70 Zone Card ZC1 8B is a plug in speaker or strobe zone card It into a slot in either the OMM 1 or OMM 2 ZC1 8B contains 8 class B speaker or circuits The 8 zones can be divided into of 3,3 and 2 where each group can be either or speaker circuits Strobe circuits are limited to amps 24VDC each When used for 25V speaker each zone is rated at 45 Watts maximum used for 70V speaker circuits each zone is rated 70 Watts maximum The maximum ZC1 8B card all wattage is 300 watts For applications that high speaker loads on a single zone ZC1 8B are capable of up to 3 100 Watt 70V speaker when audio is supplied by 3 separate EL 410D For strobe or non coded horn applications ZC1 8B card all zones is rated for a maximum load of 14.4 amps 24Vdc If power limiting of are required the PLC 4 and the appropriate PL864 25A PL864 70A PL864 25S current module s is required NUMBER Module PL864 25S current limiting module s are required 2 Channel Audio 25V or 70V Zone ZC2 8B is a plug in 25V or 70V speaker zone card plugs into a slot in either the OMM 1 or the OMM 2 ZC2 8B contains 8 Class B dual channel circuits When used for 25V speaker circuits zone is rated at 45 Watts maximum When used 70V speaker circuits each zone is rated at 70 Watts The ZC2 8B total speaker load wattage for all zones maximum is 100 Watts For applica that require high speaker loads on a single zone ZC2 8B is capable of a single 100 Watt 70V audio If power limiting of zones is required the PLC 4 the appropriate PL864 PL864 25A PL864 70A 3 channel audio 25V or 70V Zone card ZC3 4AB is a plug in speaker or strobe zone card plugs into either the OMM 1 or the OMM 2 cardcage ZC3 4AB contains 4 class A or class B three speaker circuits or Class A or B strobe circuits horn circuits are limited to 1.8 amps each When used for 25V speaker circuits zone is rated at 45 Watts maximum When used 70V speaker circuits each zone is rated at 70 Watts The ZC3 4AB total speaker load wattage for all zones maximum is 100 Watts For applica that require high speaker loads on a single zone ZC3 4AB is capable of a single 100 Watt 70V zone If power limiting of zones is required the and the appropriate PL864 PL864 25A PL864 current limiting module are required 2 Channel audio 25V or 70V Zone card ZC2 4AB is a plug in speaker or strobe zone card plugs into either the OMM 1 or the OMM 2 cardcage ZC2 4AB contains 4 class A or class B dual speaker circuits or Class A or B strobe circuits horn circuits are limited to 1.8 amps each When used for 25V speaker circuits zone is rated at 45 Watts maximum When used 70V speaker circuits each zone is rated at 70 Watts The ZC2 4AB total speaker load wattage for all zones maximum is 100 Watts For applica that require high speaker loads on a single zone ZC2 4AB is capable of a single 100 Watt 70V zone If power limiting of zones is required the and the appropriate PL864 PL864 25A PL864 or Z or Z or or or or and or or or or PL864 25S current limiting module are required Power Limiting Card PLC 4 is a plug in audio signal and 24Vdc power option card It plugs into a slot in either the or the OMM 2 cardcages The PLC 4 has four slots for mounting of the appropriate power circuit modules PL864 25A PL864 70A PL864 If power limiting of speaker or strobes zones on MXLV system are required the PLC 4 card must be with the appropriate PL864 modules Volt Audio Signal Power Limiting Module PL864 25A mounts on one of the four available on the PLC 4 card When power limited 25 volt zones are required on any versions of the zone cards ZC1 8B ZC2 8B ZC2 4AB ZC3 one PL 864 25A is required per EL 410D amplifier Volt Audio Signal Power Limiting Module PL864 70A mounts on one of the four available on the PLC 4 card When power limited 70 volt zones are required on any versions of the zone cards ZC1 8B ZC2 8B ZC2 4AB ZC3 one PL 864 70A is required per EL 410D amplifier Volt D C Strobe Circuit Auxiliary Power Power Limiting Module PL864 25S mounts on one of the four available on the PLC 4 card When power limited strobe are required on any versions of the MXLV zone ZC1 8B ZC2 8B ZC2 4AB ZC3 4AB one PL is required for each auxiliary power supply The power limits auxiliary power supplies to a load of 4 amps 24VDC Information Channel Audio Strobe Card 8 Class B Zones Channel Audio Strobe Zone 8 Class B Zones Channel Audio Strobe Zone 4 Class A or B Zones Channel Audio Strobe Card 4 Class A or B Zones Limited Card 25V Audio Power Limiting Module 70V Audio Power Limiting Module 24VDC Strobe Circuit P S Power Module Notification Appliances Horn Strobes Profile Profile
