Siemens ADBH-11 Audible Base, Data Sheet

Data Sheet Safety Security Products Detectors Base for Model Intelligent Analog Detectors ADBH 11 AND ENGINEER SPECIFICATIONS Compatible with Model detectors Produces 85dB audible signal temporal or steady Surface mounting UL 268A 464 Listed ULC Listed and NYC Fire Dept Approved Overview Model ADBH 11 audible base is designed for with analog addressable Models HFP 11 and detectors Each Model ADBH 11 contains pre wired audible piezo electric device that an 85dB signal for localized annunciation application includes all areas that normally require localized audible annunciation as hotel motel apartment condominium dormitory rooms ADBH 11 consists of a standard Series combined with supportive circuitry for the detectors and an audible device All wiring terminates at two 2 of the 4 four terminal blocks located on the back of ADBH 11 Model ADBH 11 can be used the FireFinder XLS family of fire alarm panels FACPs different configurations can provide signal circuit power to Model ADBH 11 See the typical Installation Wiring Diagram the supervision state no alarms the of the power to all Model ADBH 11 is in reversed normal state resulting zero current flow to each base with the unit Industry Inc Technologies Division any alarm is reported to the FACP the power all Model ADBH 11 detectors reverses polarity there is no audible sound The system may selectively command Model ADBH 11 under control to become audible All ADBH 11 bases are capable of sounding individually or in any combination depending upon the system program and control Model ADBH 11 is UL 268A 464 Listed achieves the audibility sound output of 85 dBs at 10 feet installation of a jumper wire between 3 and 4 of Model ADBH 11 changes the output from steady to temporal Note ADBH 11 is a smoke detector accessory combining detector and audible device functions Model ADBH 11 meets the requirements for smoke alarms as specified in UL217 and multiple station smoke alarms used in conjunction with listed compatible equipment Model may be used in lieu of single multiple station smoke alarms achieve enhanced system level functionality Compatible with Model ADBH 11 HFP 11 HFPO 11 HFPT 11 Series Audible Base 6305 for Ordering 500 033210 Detector Base for Detectors Data ADBH 11 is compatible only with the addressable detectors smoke detectors used with Model ADBH 11 subject to the maximum 30 ft center 900 sq ft as referred to in the Fire Protection Association Standard This spacing however is based on ideal namely smooth ceiling no air and no physical obstructions the fire source and the detector aforementioned center spacing format be referred to as a guide for detector layout Do not mount detectors in close to ventilating or air conditioning Exposed joists or beamed ceilings may effect safe spacing limitations for detectors is mandatory that NFPA 72 guidelines and engineering judgment be applied in to detector locations and spacing This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2012 sheet dated 6 10 2
