Siemens CAB2-BD CAB2-RD and CAB3-BD CAB3-RD Medium and Large Enclosure Doors, Installation Instructions

Installation Instructions CAB2 BD RD and CAB3 BD RD and Large Enclosure Doors Models CAB2 BD RD and CAB3 BD RD Enclosure Doors from Siemens Inc are used with the CAB2 BB RB and CAB3 BB RB Enclosure Two doors an outer and an inner are required for each enclosure The and CAB3 BD outer and inner doors are black the CAB2 RD and CAB3 RD doors are red and inner doors are black outer door consists of the door frame and either two or three removable panels on the enclosure size two for the CAB2 and three for the CAB3 Each panel is secured to the door with 10 32 nuts The removable panels may clear OD LP blank OD BP R or vented OD GP R depending on the applica The OD BP R and OD GP R panels are red The outer door is attached to the by hinge pins and secured to the backbox by keyed latch inner door has two or three openings in it for the installation of an operator and other modules There are eight threaded studs around each opening on inner door These threaded studs allow equipment installation on the door The is secured by 10 32 nuts The inner door is permanently hinged left is to the backbox by hinge pins and is secured to the backbox by a turn or a 10 32 x 1 2 screw user provided if desired and CAB3 BD RD Enclosure Doors are for indoor use only in dry the direction that the outer door is to open If the door is to open to the no further action is required If the door is to open to the right the hinges must moved to the right side of the backbox and the outer door lock must be moved to left side of the outer door See page 2 Door handle for the inner door comes taped to the outside of the inner door Remove tape from the handle and from the door To insert the handle press the handle the front of the opening in the inner door It will snap into place Refer to 1 Door 315 033008 8 Industry Inc Technologies Division 1 Handle Into Opening In Inner Door door hinge and lock reversal if required the location of the two rubber bumpers on the right side of the then remove them the upper door hinge turn the hinge upside down and install on right side of the backbox Refer to Figure 2 2 Door Hinge Revesal the above procedure for the lower door hinge Industry Inc Technologies Division 315 033008 8 On the right side of the outer door remove the ground strap Reinstall the strap on the left side of the outer door Refer to Figure 5 page 4 the rubber bumpers on the left side of the backbox Refer to Figure 3 On the right side of the backbox remove the lock bracket Reinstall the lock on the left side of the backbox Refer to Figure 3 3 Bracket And Rubber Bumper Reversal the plug s for the lock s on the left side of the door On the right of the door remove the lock s Reinstall the lock s on the left side of door Reinstall the plug s on the right side of the door 4 The Door Lock s And Plug s Industry Inc Technologies Division 315 033008 8 DOOR 5 The 12AWG Ground Strap the Inner Door the hinge pins on the inner door in the hinges on the backbox Refer to 6 6 Hinge Pins Into Inner Door Hinges blank plates as needed in unused spaces on door and secure with nuts Refer to Table 1 and Figure 7 LVM and FMT one module width each mount to the inner door No other PSC 12 PSX 12 CC 5 CC 2 may be located behind these modules Industry Inc Technologies Division 315 033008 8 7 Blank Plates In CAB2 And CAB3 Inner Doors the inner door and secure with the turn fastener Refer to Figure The inner door can also be secured with a screw if desired the Outer Door the hinge pins on the outer door in the hinges on the backbox clear blank or vented removable panel s as required and secure 10 32 nuts Refer to Table 2 and Figure 8 Industry Inc Technologies Division 315 033008 8 OUTER DOOR OUTER DOOR 8 Plates For CAB2 And CAB3 Outer Doors Industry Inc Technologies Division 315 033008 8 the ground strap on both the inner and outer doors Refer to Figure 9 the outer door and secure with the key latch 9 The 12 AWG Ground Straps On The Inner And Outer Doors inner and outer doors can be used with CAB2 BB RB backboxes only inner and outer doors can be used with CAB3 BB RB backboxes only 26 1 8 x 1 1 4 x 44 3 4 26 1 8 x 1 1 4 x 62 1 2 Industry Inc Technologies Division 315 033008 8 Industry Inc Technologies Division Park NJ Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario L6T 5E4 Canada
