Installation Instructions FHA2032 U1 Bracket for FHB2002 U1 R1 Backbox Model FHA2032 U1 S54430 B43 A1 from Siemens Industry Inc is an optional bracket that can be purchased separately for use in Seismic applications FHA2032 U1 is for indoor use only in dry environments all system power before installation first battery then AC To power up the AC first then the battery to Figure 1 to installing the FHA2032 U1 battery bracket install the FHB2002 U1 R1 as described in the FHB2002 U1 R1 Installation Instructions A6V10335922 the BP61 18AH battery set in the FHB2002 U1 R1 backbox the FHA2032 U1 battery bracket in the FHB2002 U1 R1 backbox by the three holes in the bracket with the three studs above the as shown in Figure 1 the bracket in place with the three 10 32 nuts provided 1 the FHA2032 U1 Battery Bracket x 3 3 16 x 5 3 4 A6V10334280 a en Industry Inc Technologies Division page has been left intentionally blank Industry Inc Technologies Division Park NJ Canada Limited Technologies Division Kenview Boulevard Ontario L6T 5E4 Canada A6V10334280 a en
