Siemens FHA2042-U1 Battery Bracket for the FHB2005-U1 R1 Backbox, Installation Instructions

INSTRUCTIONS FHA2042 Bracket for the FHB2005 U1 R1 Backbox Model FHA2042 U1 from Siemens Industry Inc is an optional bracket for 33Ah batteries that is used the Desigo FV2025 2050 or Cerberus PRO FV922 924 systems is installed in seismic applications The FHA2042 U1 battery bracket is designed for indoor use only in dry protected environments The or extension to the Desigo and Cerberus PRO part numbers identifies the paint and sales channel through which the part is marketed A in the extension designates that part is painted black an designates that the part is painted red to meet local code The numeral following the color designation identifies the sales channels for the part as follows 1 All channels 2 Desigo 3 Cerberus PRO FOAM STRIPS TO INSIDE BRACKET AS NEEDED TO BATTERY MOVEMENT NUT 3 33 AH BATTERIES NUT QTY 3 1 the FHA2042 U1 Battery Bracket Industry Inc Technologies Division Park NJ QTY 3 BRACKET x BOLT QTY 3 The FHB2005 U1 R1 backbox must be installed per Installation Instruction A6V10359788 the 2 12V 33 AH batteries and the FHA2042 U1 battery bracket are installed The FHA2042 U1 battery bracket is designed for use with 2 12V 33 AH batteries each having of 75 8 W x 5 D x 7 H that all power connections are removed from the backbox before installing FHA2042 U1 battery bracket If the batteries have been installed disconnect the first then the AC power supply Referring to Figure 1 place the 2 12V 33 AH battery set in the FHB2005 U1 R1 backbox the FHA2042 U1 battery bracket in the FHB2005 U1 R1 backbox by aligning the three in the bracket with the three studs above the batteries Thread the three 10 32 nuts onto the mounting studs and tighten Fasten the battery bracket to the bottom of the backbox using the three sets of 10 32 nuts and FHA2042 U1 battery bracket can only be used with the FHB2005 U1 and FHB2005 R1 backboxes the 2 12V 33 AH battery set WITH PART 3 10 32 x bolt 6 10 32 self locking nut dimensions lbs L x 7 H x 71 8 D Dimensions include tabs Industry Inc Technologies Division Park NJ Canada Limited Technologies Division Kenview Boulevard Ontario L6T 5E4 Canada ID A6V10370385 en a A5Q00058153
