Siemens RC-30U Confirmation Module, Installation Instructions

Installation Instructions RC 30U Module Alarm Verification Confirmation Module Model RC 30U is designed to against unwanted system alarm operation which result as an example from the presence of occa momentary but harmless products of combustion RC 30U will interrupt the transmission of an alarm to the system control panel for a factory set period 20 seconds however it is adjustable from 1 to 60 sec Immediately following the interruption period a period is in effect during which time a subse alarm signal if present will be sent immediately to control panel This confirmation period as factory set approximately 1 minute however it is dependent upon interrupt setting the confirmation period should an alarm signal be it will put the system into alarm condition Confirmation Module is placement sensitive as follows Modules connected between the Confirmation receptacle P2 and the control panel are not by its operation Modules connected subsequent to receptacle P1 of Confirmation Module may be affected This is by which plug system or zone is used system plug orange wire is for basic applications a single alarm interrupt confirmation cycle is suffi See Typical Connection 1 In this application a Plug Harness Assembly is used between recep P4 and P5 and any alarm signal from a module to receptacle P1 will be interrupted for a se period of time from 1 to 30 seconds 20 seconds is standard setting During this period power to the on receptacle P1 is removed a yellow LED is il and a system trouble signal is initiated In addi a high going signal 20mA is present on a terminal use as a pre signal or for connection to a recording Immediately following the interruption period the power is restored the yellow LED is extinguished the system trouble signal is canceled This also starts confirmation period a period during which time if any signal is present it will be passed through uninter to the control panel and the system will go into condition This confirmation period is variable to the that it is a multiple of the duration of the interruption one minute is standard If no alarm signal is during the confirmation period the RC 30U resets and the system is normal zone plug white wire is used for applications requir various alarm interruption confirmation cycles two or RC 30Us will be needed See Typical Connection In this application only alarm signals from modules to receptacles P1 will not be interrupted con The interruption and confirmation cycle described apply in a zone mode A yellow trouble LED is pro on the RC 30U to annunciate a specific trouble the RC 30U Model RC 30U which occupies two standard module is placement supervised providing a system signal upon removal from the system In addition of the system zone plug and or the special Plug Assembly provides a system trouble signal Information Requirements 5mA of interruption period 100mA 24VDC max of confirmation period 62mA 24VDC max 40mA max Mount module horizontal mounting in the control enclosure the Model JA 5 5 in long bus connector cable between receptacle P2 of the module and P1 of the module or control panel preceding it in the bus Industry Inc Technologies Division Park NJ 315 085462 7 Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario 5E4 Canada If the preceding module is on another row in enclosure a JA 24 24 in long bus connector assembly will be required Wire the circuit s as described in the CP 35 Control Instruction Manual P N 315 085063 Installation Wiring Refer to the Wiring illustration Modules are to be bus connected from right to left two row enclosures the modules in the lower row to be connected from left to right Succeeding rows to be alternately connected right to left left to etc a module is the last module in the system install a JS 30 30 in long or JS 64 64 in long bus assembly from the unused receptacle of last module to terminal 41 of the CP 35 control This completes the module supervision circuit If a zone is not used the EOL device should connected to the alarm initiating circuit terminals 2 3 Zone 1 or 4 and 5 Zone 2 of the module a supplementary relay module annunciator or output module is used then the alarm outputs 1 Zone 1 and 6 Zone 2 should be to these units Test to the CP 35 Control Panel Instruction Manual In and Wiring P2 is the incoming bus plug and must be connected to the When the RC 30U module is installed apply the WARNING Note the specific color of the zone plug and the system plug system plug orange confirms all zones as a function of a alarm whereas the zone plug white may confirm some and not others Refer to the plug arrangement and the controlled in the above examples panel Operation The RC 30U interrupts the transmission of an alarm to the system control panel for a factory set period of 15 Immediately following the interruption period a period is in effect during which time a subsequent signal if present is sent immediately to the control panel confirmation period is factory set at 1 minute The RC 30U cannot be used to confirm shorting zones 315 085462 7 Terminals 1 and 2 are provided in case a trouble output delay is If it is remove jumper terminals 1 and 2 and connect 1 of RC 30U to terminals 1 and 2 of the TL 30U and 2 of RC 30U to terminal 3 of the TL 30U The TL 30U must not exceed 200 seconds P N 575 287974 enclosed to the inside of the control unit where it is plainly visible Minimum wire size 18 AWG wire size 12 AWG Refer to P N 315 093680 for power limited connections All terminals are non power limited on the RC 30U
