Siemens RPM (for FireFinder) Remote Printer Module, Data Sheet

s XLS Printer Module RPM Provides an interface to remote printers 2 serial ports and 1 parallel port provided Supervised intelligent module Plain decimal addressing Supports Class B Style 4 or A Style 7 wiring Provided in its own enclosure Built in transient protection Downloadable module firmware UL 864 9th Edition Listed ULC Listed CSFM NYMEA Approved Overview Remote Printer Module Model RPM provides a of connecting the FireFinder XLS system to a printer for creating a hard copy of system status configuration reports Simultaneously the RPM a Foreign System Interface FSI output port can be configured to communicate with external such as Building Management systems RPM is remotely connected to the H Net communi bus from any NIC C output in a FireFinder XLS enclosure and uses Class B Style 4 or A Style 7 wiring There are two 2 RS 232 serial and a single parallel port that allow connection to parallel printer such as the PAL 1 with the operation of the FSI port or a serial port FSI serial port can be configured as RS 232 or and will provide data to a monitoring system no control capabilities Industry Inc Technologies Division FSI is also to be used for primary or secondary of the FireFinder XLS by the foreign system of the FireFinder XLS through this port is only for use with authorized UL approved prod The communication is bi directional and includes to verify that data sent by the FireFinder has been received by the monitoring system the PAL 1 is used with the RPM the RPM super the printer for On Off Line Power On Paper Paper Jam and wiring fault conditions as by UL for NFPA 72 proprietary systems and report printing is generated at the Person Interface PMI on the main FireFinder XLS RPM has integral mounting flanges to allow module to be mounted unobtrusively under a or behind a desk 24VDC is required to run the and can be provided from a model PSC 12 Power or PSX 12 Power Supply Extender in the XLS system enclosure XLS 6325 continued from other UL Listed 24VDC power sources also acceptable The RPM has screw terminals of supporting 12 to 22 gage wires with the FireFinder XLS system is by connection to the NIC C network interface using Class B Style 4 or Class A Style 7 wiring H Net communication from the FireFinder XLS can be terminated on the RPM or may pass for communication with other modules LEDs on the RPM indicate power and status and Humidity Range are UL 864 9th Edition listed for indoor locations within a temperature range of 49 2 to 32 3 0 2 and a relative humidity of 93 2 at a temperature 90 3 32 2 Ratings Back Plane Current Terminal 24V Current Back Plane Current Standby Current for Ordering Printer Module for FireFinder XLS System UL Listed Parallel Printer This marketing catalog sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2010 sheet dated 10 09 3
