Siemens SP4-LOC-FB Remote Microphone and Local Operator Console, Data Sheet

Data Microphone and Local Operator Console AND ENGINEER SPECIFICATIONS All message wiring is pre wired to a terminal block Internal terminal block accepts up to 16 AWG wiring for filed wiring Back boxes are identical with knockout mounting holes the sides and back Each back box contains three 3 double knockouts for 1 2 or 3 4 conduit fittings Knockouts are located in the top and bottom center of the back box as well as at top center portion in the back part of the console Remote microphone disengages any airing of music BGM and general paging Built in Model SPRM requires 24VDC nominal which is supplied by Model SP40S Models available for flush or surface mounting Can be mounted up to 2,000 feet 610 meters from Model SP40S Eight 8 ON OFF push buttons that provide contact closure while in the ON position Push buttons are BLACK in the OFF position GREEN in the ON position All output circuitry is power limited OSHA 1910.165 ADA and FCC Part 15 Compliant UL 864 9th Edition Listed ULC Listed CSFM NYC Fire Department Approved Overview Remote Microphone and Local Operator Console is designed for indoor use with SAFEPATH Emergency Communications Voice System Models SP40 2 and SP40S mass applications contains the remote module as well as eight 8 ON OFF push that provide a contact closure used to activate Model SP40S digital messages in the ON position buttons change color from BLACK in the OFF to GREEN in the ON position A message plate holder is located above each push Remote Microphone module Model SPRM a push to talk PTT microphone and status light emitting diode LED indicators Local Operator Console SP4 LOC FB SPRM provides a microphone override for any generation digital voice module prerecorded background music or telephone paging SPRM is equipped with a key lock that when permits the use of the module SPRM which is fully supervised from Model contains front panel LEDs for remote of Trouble and Alarm Model is orderable as two 2 parts The flush mount version has a skirt around the door section while the model has its door molding flush with back box Remote Microphone and Local Operator Console 3756 Industry Inc Technologies Division Overview continued Remote Microphone and Local Operator Console the same white 4 inch deep back box with one double knockout in the center of back of each console as well as the top and of the back box Both models have a pull Latch to open the continuous hinged door Remote Microphone and Local Operator Console be for use with SAFEPATH Emergency Voice Evacuation System This shall contain the SAFEPATH Remote Module Model SPRM and eight 8 black OFF push buttons that provide a contact closure push buttons shall change color from BLACK in OFF position to GREEN in the ON position A plate holder is located above each button Data Requirement Frequency W x H W x H x D nominal 22 Wire Gauge AWG shielded six wire conductor Hz 6.5 KHz 2.4 dB 16 1 4 cm 41.3 cm 15 1 2 4 cm 39.4 cm 10.2 cm for Ordering S54459 C34 A1 Flush mount local operator console S54459 C35 A1 Surface mount operator console This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2012 Issue 0
