Siemens VPM, VPM-MP and VESDA-HLI-KIT VESDA High-Level Interface Equipment, data sheet

Fire Safety System High Level Interface Equipment VPM VPM MP and VESDA HLI KIT Architect Engineer Specifications Addressable Intelligent and module Allows for a single point of control at Desigo Fire Safety Modular system with bi directional data to VESDA networks Capability for Desigo Fire Safety system to annunciate Alert Fire 1 and Fire 2 levels select detectors on any VESDA Supports two 2 independent VESDA with up to 100 VESDA each Downloadable module firmware Main panel enclosure or remote panel Approved UL 864 Listed ULC Listed Product Overview Very Early Smoke Detection Apparatus VESDA Peripheral Module Model VPM the VESDA High Level Interface Kit Model VESDA HLI KIT are all optional that work in combination to provide bi directional communication between Desigo Fire Safety Modular system fire alarm control panel FACP and multiple detection networks for the following types of VESDA detectors VEU VEP VES VPM allows each Desigo Fire Safety system FACP to annunciate 1 and 2 levels as well as from select detectors on a VESDA network Model VPM allows a Model Operator OI to detailed Trouble event codes by VESDAnet When used with a LaserSCANNER a Model FCM2041 OI displays the events to an individual VPM Mounting plate Model VPM MP allows the of one 1 Model VPM and two 2 of VESDA HLI KIT inside a standard Desigo Fire Modular System Model CAB1 Model CAB2 or CAB3 enclosure Model VPM MP utilizes two module spaces on a single row of each VESDAnet Socket Card provides the terminals to the VESDAnet field wiring as well as the power for the high level interface HLI card is mounted on a Model VPM MP stand offs stand offs are available on Model VPM MP a second card be needed Infrastructure Building Products Model VPM MP Sheet 7357 power of 24VDC nominal is required to Model VPM and can be provided from either a PSC 12 Power Supply or Model PSX 12 Supply Extender located within the Desigo Safety Modular system enclosure Model VPM also be powered by the Siemens auxiliary supply and Humidity Range are UL ULC Listed for indoor dry locations a temperature range of 120 3 49 2 to 0 2 and a relative humidity of 93 2 at a of 90 3 32 2 Ratings BACK CURRENT TERMINAL 24V CURRENT BACK PLANE CURRENT STANDBY For power supply loads as well as battery size each Model VPM module draws 150mA screw terminal current plus 70mA for each VESDA HLI KIT inserted under each Model for Ordering TYPE Peripheral Plate for Peripheral High Level Model VPM contains two 2 RS serial ports connection to two 2 independent VESDA high interfaces Model VESDA HLI KIT includes one 1 of the following devices VESDA HLI VESDAnet socket for connection to the VESDA network 10 position 9 22.9 cm cable for connection between Model VPM and VESDA HLI 3 wire 6 15.24 cm cable for connection between Model VESDA HLI VESDAnet socket VESDA high level interface supports up to 100 detectors of the following types MODEL TYPE VES Ultra Plus 1 4 pipe units Scanner NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information Detector model with Siemens HLI compatibility using mode Refer to latest version of install doc for details VPM connects to a FACP via a RS interface to the Desigo Fire Safety Modular System Interface Card Model NIC C allowing a VPM and Model VESDA HLI KIT combination to mounted up to 2,000 feet from the main FACP further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product Industry Inc Infrastructure Building Products Fernwood Road Florham Park NJ 07932 973 593 2600 2021 3
