Silent Knight 5700spec

INTELLIKNIGHT FIRE ALARM CONTROL PANEL Model 5700 Loop Addressable Alarm Control System affordable addressable fire alarm panel solution Model 5700 is a 50 point class leading single loop fire alarm control communicator system 5700 provides you the revolutionary value and performance of addressable sensing combined with exclusive built in digital communication intelligent power that includes an easy to use interface Powerful features such as drift compensation maintenance alert are delivered in this powerful FACP from Silent Knight more information about the IntelliKnight system or to locate your nearest source please call or in Minnesota call 763 493 6435 performs drift compensation and checks on each of the in the system basic IntelliKnight 5700 system be enhanced by adding modules as 5860 remote annunciator serial parallel printer interface for printing system reports 5496 intelligent power module also features a powerful built in line fire communicator that allows reporting of all system activity to a monitoring location Up to 50 addressable points Up to 125 zones and 125 output Uses standard wire shielded or pair required Built in digital communicator Central station reporting by point or zone Supports Class B Style 4 and Class Style 6 or 7 configuration for SLC Distributed intelligent power Drift compensation 13 pre programmed output cadences ANSI 3.41 and 4 outputs Notification circuits configurable as 1 A Style Z or 2 Class B Style or auxiliary power for resettable or door holder power Built in synchronization for AMSECO Faraday System Sensor Wheelock appliances Built in annunciator with 80 character display RS 485 bus provides communication system accessories Upload or download programming history or detector status or from a remote location a PC and 5660 Silent Knight Suite SKSS Improvements in SKSS deliver five faster upload downloads Built in RS 232 interface for via PC Built in Form C trouble relay rated at at 27.4 VDC Two built in Form C programmable rated at 2.5A at 27.4 VDC Programmable date setting for Saving Time Specifications AC 120 VAC 60 Hz 1.5A Accessory Load 2.5A 27.4 Power 2.5A 27.4 VDC Current 200 mA Current 325 mA Power Circuits 27.4 VDC per circuit Charging Capacity 7.0 35.0 AH Size 7 AH max allowed in cabinet Larger capacity can be housed in an RBB cabinet Specifications W x 15.2 H x 3.4 D W x 38.42 H x 8.57 D cm 11.5 lbs 5.2 kg Red 5700 Requirements Part 15 and Part 68 approved of Jack RJ31X two required 13 NFPA 15 NFPA 16 NFPA NFPA 72 Central Station Signalling Local Protective Systems Auxiliary Protected Unit Water Deluge Service Suitable for manual waterflow sprinkler DACT non coded services Approvals UL Listed 7170 0559 144 429 92 E Vol XVI FIRE ALARM CONTROL PANEL Detectors photoelectric smoke detector ionization smoke detector temperature heat detector that into alarm immediately if the exceeds the programmable trip Trip point range from 135 inch base for use with detector heads SD505 AIS and SD505 AHS inch base for use with detector heads SD505 AIS and SD505 AHS sounder base for use with existing and base Operates in single and modes and or as a system Requires 2 additional wires for circuit isolator base for SD505 AHS and SD505 AIS detectors relay base for use with existing and base Provides one Form C housing that detects smoke in HVAC detector base with relay Provides C alarm contact For use with and SD505 AIS sensors with SD505 DTS remote test is a single action pull station and is a dual action pull station Modules SD500 AIM contact input module for use with open dry contacts It features an LED to show alarm status dry contact input module is a small of the SD500 AIM For use with pull and other normally open dry contact notification module providing a Class A or Class B notification circuit the SLC relay module that features two C output relays Provides indicator to show output status detector input module Allows for connection of conventional 2 wire on the SLC loop Requires two wires for power short circuit isolator module for SLC When a short occurs on the SLC it is detected as a trouble but all SLC protected by the isolator module to operate LED driver capable of driving 80 LEDs the SLC loop Up to 40 can be used per system Accessories Remote Fire Annunciator the same 80 character backlit LCD keypad and firefighter key switch the 5700 The system can be fully and operated from any 5860 is gray and 5860R is red Intelligent Power Module 6 amp notification power expander that four additional power limited appliance circuit outputs LED IO Module 40 LED 8 normally dry contact inputs one piezo output and 5865 4 LED 30 LED 15 and 15 yellow outputs and a piezo The 5865 4 adds a silence and switch to the package Relay Board 10 general purpose Form C relays with 5880 module Serial Parallel Printer Module one parallel and one RS 232 serial for connecting a printer to 5808 Use to a real time log of system events status reports and event history with building control system Accessories Silent Knight Software Suite Windows software for remote of 5700s using a PC Upload view panel account information event and detector status Silent Knight Software Suite facility management software viewing of detector status and event via modem or direct connection Battery Box Accessory Cabinet Use backup batteries are too large to fit into cabinet Dimensions W x 10 H x 6 D mm W x 254 mm H x 152 mm D test switch that provides remote key test function and annunciation of alarm with SD505 ADHR document is not intended to be used for installation purposes We try to our product information up to date and accurate We cannot cover all applications or anticipate all requirements All specifications are to change without notice For more information contact Silent Knight Meridian Circle Suite 100 Maple Grove Mn 55369 4927 800 328 0103 Fax 763 493 6475 JumpStart are Registered Trademarks of Silent Knight is a Trademark of Silent Knight IN AMERICA 350392 Rev D 04 06 2006 Silent Knight
