Silent Knight IDPphoto isheet

57.2 fixed temperature heat detector refer to the operation manual for the UL listed unit for specific operation of the IDP Photo IDP and IDP Acclimate IDP Photo IDP Photo T and IDP Acclimate require addressable communications to function Connect these sensors to listed compatible panels only Knight recommends spacing sensors in compliance NFPA 72 In low air flow applications with smooth space sensors 30 feet apart For specific information sensor spacing placement and special refer to NFPA 72 Applications IDP Photo and IDP Photo T are listed use in ducts These products are not listed for use inside duct detectors GUIDE wiring must be installed in compliance with the Electrical Code applicable local codes and any requirements of the Authority Having Jurisdiction wire gauges should be used The installation should be color coded to limit wiring mistakes and system troubleshooting Improper connections will a system from responding properly in the event a fire power from the communication line before sensors Wire the sensor base supplied separately per the diagram see Figure 1 Set the desired address on the sensor address switches Figure 2 Install the sensor into the sensor base Push the sensor into base while turning it clockwise to secure it in place After all sensors have been installed apply power to control unit and activate the communication line Test the sensor s as described in the TESTING of this manual covers provide limited protection against airborne particles during shipping Dust covers must be before the sensors can sense smoke Remove prior to heavy remodeling or construction IDP Photo IDP Photo T and IDP Acclimate a tamper resistant capability that prevents their from the bracket without the use of a tool Refer to base manual for details on making use of this capability IDP Photo T and Intelligent Smoke Sensors and Maintenance 0 to 38 to 100 IDP IDP Acclimate inches 51mm in SS B6 Base inches 155 mm in SS B6 Base inches 104 mm in B501 Base to 32 VDC Voltage Range 24 VDCMax Current mA 24 VDC Current LED on to 93 Relative Humidity Range non condensing Temperature Range 0 to 49 32 to 120 sensor must be installed in compliance with the panel system installation manual The installation meet the requirements of the Authority Having AHJ Sensors offer maximum performance installed in compliance with the National Fire Association NFPA see NFPA 72 DESCRIPTION IDP Photo IDP Photo T and IDP Acclimate plug in type smoke sensors that combine a sensing chamber with addressable communications The sensors transmit an analog of smoke density over a communication to a control panel Rotary decade switches are for setting the sensor address LEDs on the sensor are controlled by the panel indicate sensor status An output is provided for to an optional remote LED annunciator P N Models IDP Acclimate and IDP Photo T a photoelectronic sensing chamber and 135 oz 147 g ANNUNCIATOR RETURN LOOP 1 Wiring Diagram Do Not Loop Wire Under Terminal 1 or 2 Wire Run To Provide Supervision of Connections 0 0 2 Rotary Address Switches T est t Magnet Status T est t Magnet 3 testing notify the proper authorities that the system undergoing maintenance and will temporarily be out of Disable the system to prevent unwanted alarms sensors must be tested after installation and periodically Testing methods must satisfy the Authority Jurisdiction AHJ Sensors offer maximum when tested and maintained in compliance NFPA 72 sensor can be tested in the following ways Functional Magnet Test P N M02 04 01 or M02 09 00 This sensor can be functionally tested with a test The test magnet electronically simulates in the sensing chamber testing the sensor and connections to the control panel 1 Hold the test magnet in the magnet test area as shown in Figure 3 2 The sensor should alarm the panel Two LEDs on the sensor are controlled by the panel indicate sensor status Coded signals transmitted the panel can cause the LEDs to blink latch or latch off Refer to the control panel technical for sensor LED status operation and delay to alarm Smoke Entry Aerosol Generator Gemini 501 or UL lised devices The GEMINI model 501 aerosol generator can be for smoke entry testing Other UL listed smoke devices may be used as well Set the to represent 4 ft to 5 ft obscuration as in the GEMINI 501 manual Using the bowl applicator apply aerosol until the panel alarms For IDP Acclimate smoke entry testing should be immediately following the magnet test test initiates an approximately 10 minute period the detector signal processing software routines not active Failure to first perform the magnet test introduce a time delay before the detector alarms Direct Heat Method Hair dryer of 1000 1500 IDP Photo T and IDP Acclimate only A hair dryer of 1000 1500 watts should be used to the thermistors Direct the heat toward either the two thermistors holding the heat source 12 inches from the detector in order to damaging the plastic housing The detector will only after it has had sufficient time to cool Make both thermistors are tested individually sensor that fails any of these tests should be cleaned as under CLEANING and retested If the sensor fails cleaning it must be replaced and returned for repair testing is complete restore the system to normal and notify the proper authorities that the system back in operation removing the detector notify the proper that the smoke detector system is undergoing and will be temporarily out of service the zone or system undergoing maintenance to unwanted alarms Remove the sensor to be cleaned from the system Remove the sensor cover by pressing firmly on each the four removal tabs that hold the cover in place Vacuum the screen carefully without removing it If cleaning is required continue with Step 4 otherwise skip to Step 7 Remove the chamber cover screen assembly by it straight out Use a vacuum cleaner or compressed air to remove and debris from the sensing chamber Reinstall the chamber cover screen assembly by the edge over the sensing chamber Turn until is firmly in place Replace the cover using the LEDs to align the and then gently pushing it until it locks into Make sure that the thermistors do not become under the cover on the IDP Photo T and IDP models Reinstall the detector Test the detector as described in TESTING Reconnect disabled circuits Notify the proper authorities that the system is back line and and and IDP Acclimate Meridian Circle Grove MN 55369 4927 800 328 0103 763 493 6475 2005 Silent Knight refer to insert for the Limitations of Fire Alarm Systems Statement device complies with part 15 of the FCC Rules Operation is subject to the following two conditions 1 This device may not cause harmful and 2 this device must accept any interference received including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules These limits designed to provide reasonable protection against harmful interference in a residential in
