Silent Knight IFP2000VIPspec

Voice Integration Panel with Fire Alarm Control IFP 2000VIP is an intelligent analog addressable fire alarm control combined with an integrated single channel voice evacuation system basic IFP 2000VIP system has one onboard signal line circuit SLC which can support 159 IDP sensors and 159 IDP modules IFP 2000VIP has eight on board Flexput circuits that can be for auxiliary power notification outputs or for conventional detector inputs Class A or Class B The FACP also has a built in digital fire communicator Form C trouble relay and two Form C relays The firmware has powerful features such as sensitivity day night thresholds drift compensation pre trouble alert and calibration trouble alert IFP 2000VIP supports a variety of devices including RA 2000 remote 5824 serial parallel printer interface module for printing reports RPS 1000 intelligent power module and Intelligent Device IDP devices IFP 2000VIP places all of the critical user interface controls at the main This seamless combination of fire detection and voice evacuation simplifies operation and programming of the entire system The system is scalable from 50 to 400 watts using a distributed scheme to provide the power to the appropriate areas for coverage Built in support for up to 159 IDP sensors and 159 IDP modules to 636 points per IFP 2000 panel All the features of the IFP 2000 Fire Alarm Control Panel combined with fully integrated voice evacuation system Built in Digital Message Repeater using DSP technology Three field programmable user messages Upload download voice messages using a PC and the 7780 voice application Program voice messages via serial interface or built in microphone Support for up to eight VIP 50s 50 watt SBUS addressable amplifiers a maximum of 400 watts per system Single enclosure for both fire and voice system control components On board supervised microphone System can support two supervised remote microphones Up to 64 mappable speaker circuits using a combination of VIP 50s and Supports 25 Vrms or 70.7 Vrms speaker circuits Built in Ethernet and USB interface for programming Improvements in SKSS 2 delivers five times faster upload downloads All call and Non Alarm buttons to quickly select all active or all the non output groups 999 software zones and 999 output groups Jumpstart auto programming IFP 2000VIP can be surface or flush IFP 2000VIP is compatible with the following evacuation components VIP 50 50 watt amplifier VIP 125 125 watt amplifier VIP RM2000 remote microphone VIP SW16 16 switch expander VIP VCM voice control module Mount Dimensions 20.25 x 26.75 x 3 51.4 W x 68 H x 6.4 D cm Dimensions 20 x 26.5 x 4.6 W x 67.3 H x 11.8 D cm 53 lbs 24 kg Red Clintonville Road CT 06472 1610 or 800 328 0103 203 484 7118 350400 Rev A 2009 Honeywell International Inc is a Trademark of Silent Knight Jumpstart is Registered Trademark of Silent Knight Temperature 32 120 0 49 10 93 non condensing Primary AC 120 VAC 60 Hz 2.5A Primary AC 230 VAC 50 Hz 1.25A Accessory Load 6A 27.4 VDC power limited Current 75 mA Current 700 mA Charging Capacity 7 to 35 AH Size 18 AH max allowed in control panel cabinet capacity batteries can be housed in RBB accessory Conductor Wiring Two voice bus four SBUS Circuits circuits that can be programmed individually as Circuits 3A per circuit 27.4 VDC power limited Power Circuits 3A per circuit 27.4 VDC power Circuit 100 mA per circuit 27.4 VDC power limited 13 NFPA 15 NFPA 16 NFPA 70 72 Central Station Remote Signalling Local Protective Systems Auxiliary Protected Premises Unit Water Releasing Service Approvals UL Listing CSFM 7170 0559 160 MEA Information Integration Panel with Fire Alarm Accessories Watt Amplifier Watt Amplifier Microphone Circuit Audio Expander For VIP 50 and Switch Expander Control Module Message Downloading Application voice messages with a PC Trim Ring For flush mounting document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications anticipate all requirements All specifications are subject to change without notice more information contact Silent Knight 12 Clintonville Road Northford CT 06472 Phone 800 328 0103 Fax 203 484 7118 www farenhyt com in the U S A
