Silent Knight IFPN 2C8Mspec

Conventional 8 Dry Inputs Monitor Module IFPN 2C8M 2 control and 8 monitor NION installation provides a general purpose module for monitoring eight and controlling two outputs on an IFP NET or IFP NETUL system Each of the three installation kits provides all the components necessary to connect control panels and devices dry contacts to the IFP NET UL system The three offer the flexibility to connect to short and long or wire installations and single or two multimode fiber optic IFPN 2C8M provides eight supervised inputs for dry contacts two SPDT relay outputs Each input has alarm and trouble to indicate which input is active or in open circuit The inputs supervised with an end of line resistor A short to a circuit will an alarm and an open circuit will cause a trouble Each has an LED to indicate relay activity IFPN 2C8M sends and IFP NET UL system messages Isolating troubles or is easier because each input and output has a unique IFPN 2C8M counts as 1 of 16 nodes that the IFP NET UL can support It can be powered by any monitored or a 24 VDC power limited filtered source with battery that is UL Listed with fire protective signaling units IFP NET UL system components are based on LonWorks Provides transparent or interpreted communications between the workstation and conventional control panels and with dry contacts Includes all the components necessary to set up communications conventional control panels and devices with dry and IFP NET UL graphical monitoring center Offers SPDT control output relays rated at 5A 30 VDC Allows power source to be 24 VDC from monitored panels or UL Listed power support Supervises normally open inputs with end of line resistors Ensures reliable operation with transient protection on all and transformer coupled system connection Supports wire and single or two wire multimode fiber Allows integration of wire and multimode fiber on the same system with optional router IFPN ROUTMB or Provides an EIA 232 interface Indicates system status with four LEDs Status Service Input Output Conventional control panels with dry contacts Conventional devices with dry contacts use in wire and multimode fiber installations the IFP NET UL system where equipment functions at a local site are required IFPN 2C8M allows conventional panels and equipment to operate on the same network as Silent Knight IFP series IFPN 2C8M motherboard is mounted in the cabinet An IFPN transceiver is to the IFPN 2C8M motherboard The IFPN transceiver is then to the LonWorks network Meridian Circle Grove Mn 55369 4927 763 493 6475 350272 Rev B 05 05 06 2006 Silent Knight Platform LonWorks based system operating at 78.5 over wire or multimode fiber Bidirectional fiber 1250 IFPN 2C8MDF Support Wire T tapped or home run or multimode Requirements Multimode 62.5 125 dia IFP NET UL Standard screw terminals and Outputs Up to eight inputs and two outputs in any Cabinet Dimensions W x 16 H x 3 D cm W x 40.64 cm H x 7.62 cm D Status Service Input and Output Source From a monitored control panel or any power supply Requirements 24 VDC 200 mA Temperature 32 to 120 0 to 49 Temperature 40 to 176 40 to 80 93 non condensing at 86 30 Information packages include everything needed to add control panels and devices to an IFP NET UL IFPN 2C8M motherboard transceiver EP chipset and IFPN CAB1 cabinet installation package uses the FTXC multimode fiber installation package the FOXC transceiver Requires or 4WRMB for system topology multimode fiber installation package the DFXC transceiver For use in fiber cable installations Requires for topology change Not with 4WRMB router supports IFPN FTXC and DFXC transceivers layer repeater supports and FOCX transceivers Parts Wire transceiver multimode fiber transceiver multimode fiber transceiver replacement motherboard Requires Order separately Chipset for all 2C8M transceivers except Chipset for the IFPN DFXC transceiver IFPN DFXC Fiber systems can run longer distances than wire and are immune to noise but also require an IFPN ROUTMB or for topology change from the IFP NET UL document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications anticipate all requirements All specifications are subject to change without notice more information contact Silent Knight 7550 Meridian Circle Suite 100 Maple Mn 55369 4927 Phone 800 328 0103 Fax 763 493 6475 in the U S A
