Silent Knight SK-Control Addressable Notification ModuleData Sheet

SK CONTROL Notification Module SK CONTROL is an addressable notification module for use with Silent Knight series fire alarm control panels FACPs The provides supervised monitoring of wiring to load devices require an external power supply to operate such as bells horns and It is capable of Class B Styles Y and Class A Style Z supervision command from the FACP the SK CONTROL will disconnect the and connect the external power supply across the load device disconnection of the supervision provides a positive indication to the that the control relay actually turned on The external power supply is relay isolated from the SLC loop so that a trouble condition on the supply will never interfere with the rest of the system SK CONTROL mounts directly into a 4 square electrical box The box have a minimum depth of 2 1 8 A surface mount electrical box Sensor PN SMB500 is available from Silent Knight Flexible solution for notification where needed Polling LED visible the cover Rotary address for fast Attractive ivory cover SEMS screws for easy UL Listed Support for Class B Y or Class A Z wiring Panel controlled LED that green in state and is red in alarm BENEFITSfirealarmresources com Technical Specifications 4.5 H x 4 W x 1.3 D 11.4 cm x 10.2 x 3.2 cm INFORMATION Notification Module Voltage 15 32 VDC Power Supply Current 7mA per module Standby Current Resistance 47KW Standby Alarm Current 375mA max 24 one communication every 5 sec with 47K Loop Resistance 40W max Temperature 32 120 0 10 93 non condensing 4 Square Surface Mount Electrical Box Module Barrier SK CONTROL is compatible with the Honeywell Silent Knight fire alarm panels Addressable fire alarm control panel Addressable fire alarm control panel an emergency mass notification system Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel an emergency voice system a complete listing of all approvals and please visit Windows and Windows Logo are trademarks trademarks of Corporation Knight System and Honeywell registered of Honeywell Inc document is not to be used for purposes We to keep our product up to and accurate We cover all specific or anticipate requirements All are subject change without notice Technical Support 800 446 6444 more information more about Honeywell Silent Knight and other by visiting www silentknight com Silent Knight Clintonville Road CT 06472 350125 Rev E 11 17 2017 Honeywell International Inc
