Silent Knight SKE-SRM Remote Microphone Module Installation Instructions

SKE SRM Remote Microphone Installation Instructions mount the remote microphone cabinet Remove the SKE SRM from it packing SKE SRM is a supervised remote assembly that can be added to the voice evacuation system SKE SRM is compatible with the SKE voice evacuation system is important to protect the SKE SRM control from water To prevent water damage the conditions should be avoided when the units Do not mount directly on exterior walls masonry walls condensation Do not mount directly on exterior walls grade condensation from plumbing leaks from splash caused by sprinkler ports Do not mount in areas with humidity gener equipment such as dryers production selecting a location to mount the SKE cabinet the unit should be mounted where will NOT be exposed to temperatures outside range of 0 32 or humidity the range of 10 85 at 30 86 Unlock the cabinet and remove the cabinet Unplug microphone from microphone Place microphone in a safe while completing cabinet Remove the cover plate by un screwing the cover plate screws Set the screws aside later use Remove the remote microphone chassis by un screwing the two chassis screws See Figure 1 1 Remote Microphone Chassis Assembly 151396 Remote Microphone Module Installation Instructions Mount the cabinet using the appropriate and anchors through the cabinet holes See Figure 2 3 illustrates how to wire the SKE SRM to main control panel Limited 2 Cabinet Mounting Hole Locations shielded 4 conductor 22 AWG up to 5000 wiring for the remote microphone The is supervised by the main panel if switch on SW2 is set to ON 3 The SKE SRM Wiring Connections to the Specifications Fault Impedance To Any Terminal 0 Input Power 27.4 VDC 30 mA Input Power 27.4 VDC 30 mA Meridian Circle Grove MN 55369 4927 or 800 328 0103 763 493 6475 2005 Silent Knight PN 151396 Rev B
