Silent Knight WSK-PULL-DA Data Sheet

Intelligent Wireless Devices Wireless Pullstation Silent Knight SWIFT addressable pull station is a dual action manual pull with a key lock reset feature that provides one addressable alarm initiating The pull station features similar aesthetic design and durable construction as the wired counterpart to blend seamlessly throughout the The device communicates to the FACP through the SWIFT mesh and gateway and is powered by 4 batteries offering a 2 year UL listed battery is fast and straightforward by using a mounting plate that can be surface Once the mounting plate is firmly attached to the wall the pull station is into place and locked down with 3 screws mechanical operation is simple and easy to use in an emergency with a PUSH IN DOWN handle that latches in the down position to clearly indicate the station been operated while the word appears on top of the handle in bright further indicating the operation of the station wireless pull station meets the Americans with Disabilities Act Accessibility ADAAG controls and operating mechanisms guidelines section and the Americans with Disabilities Act ADA requirement for a 5 pound pull force to activate the pull station and conforms to ANSI UL Standard SWIFT wireless system offers intelligent addressable devices which provide reliable communication to the Fire Alarm Control Panel FACP across a Class mesh network Wireless devices create an opportunity for applications where it is concrete walls ceilings buried wires obtrusive surface mount conduit or dangerous asbestos to use traditional wired devices In addition both wired wireless devices can be present on the same FACP providing an integrated wired solution for increased installation potential BENEFITS Easy fast wireless Built in tri color LED Standard wheel Meets ADAAG controls Made of durable Participates in a Class mesh network in normal and latches red when in Maintenance Handle latches in down can open for inspection address setting causing an condition and the word appears clearly indicate the has been setting the SLC For use in commercial Smooth dual action Highly visible operating Section meets ADA for 5lb activation Meets UL 38 Standard Manually Actuated Boxes material Attractive shape and finish Key reset Includes Braille text on handle metal backbox for best performance Requires 4 CR 123A included WSK RELAY Wireless relay module for use with the WSK WGI gateway Includes a special cover with a built in tamper Recommended for installation in an SMB500 WH box separately rather than a metal backbox for best Requires 4 CR 123A batteries included WAV CRL WAV CWL SWIFT Wireless Addressable AV bases 8 CR 123A batteries included Requires a non ceiling System Sensor L series notification device separately W SYNC Wireless sync module Requires 4 CR 123A batteries SMB500 WH Optional surface mount backbox SWIFT Tools Programming and diagnostic utility Free download www silentknight com For installation on a typically laptop running an approved version of Windows See Minimum Requirements for SWIFT Tools Requires the W USB radio dongle for communication with SWIFT Wireless devices W USB Wireless USB radio antenna dongle that plugs into the port of a PC running SWIFT Tools The W USB provides a link with SWIFT Wireless devices that are within 20 feet and have not formed a mesh Alternately the devices have formed a mesh bringing the PC W USB range 20 ft of the gateway for that mesh will allow SWIFT to acquire information on all devices in that mesh including signal strength for all links W BATCART Wireless battery cartridge 10 pack For use with pullstations and AV bases mesh network within the SWIFT system creates a child parent between the devices so that each device has two parents a second path for communications on every device If one can no longer operate for any reason the rest of the devices still communicate with each other directly or through one or more devices Once an initial mesh network is formed mesh automatically occurs to find the strongest paths within the network SWIFT system also engages frequency hopping to prevent interference whether intentional or accidental Each device with part 15 of the FCC rules meaning operation is subject the following two conditions 1 The device may not cause harmful and 2 The device must accept any interference received interference that may cause undesired operation Control Panels 6700 6808 6820 6820EVS Components and Ordering Information WSK PULL DA Wireless addressable pullstation Requires 4 CR batteries included WSK WGI Wireless SWIFT Gateway 1 SWIFT Gateway is required each wireless mesh and supports up to 49 SWIFT detectors or Connects to the SLC loop of a compatible panel using SK Power may be supplied by the SLC circuit or via an 24VDC input Use of the 24VDC input may be more convenient for service as it allows for powering a gateway without shutting down an SLC loop WSK PHOTO Intelligent wireless photo detector Ships with base included Requires 4 CR 123A batteries included WSK HEAT ROR Intelligent wireless rate of rise 135 heat Ships with B501W base included Requires 4 CR 123A included WSK PHOTO T Intelligent wireless photo heat detector Ships B501W base included Requires 4 CR 123A batteries WSK HEAT Intelligent wireless fixed temperature 135 heat Ships with B501W base included Requires 4 CR 123A included WSK MONITOR Wireless monitor module Used to monitor with mechanical contact actuation Includes a special with a built in tamper magnet Recommended for in a SMB500 WH box ordered separately rather than 2 of 3 SK 61056 B 10 30 2018 Technical Specifications Transmit RF Power 17 dBm Frequency Range 902 928 MHz Range 32 to 120 0 to 49 10 to 93 Non condensing Type 4 Panasonic CR123A or 4 Duracell Life 2 year minimum Replacement Upon TROUBLE BATTERY LOW and or during annual maintenance 5.6 142 mm H x 4.2 107 mm W x 2.1 mm D LISTINGS AND APPROVALS listings and approvals below apply to the WSK PULL In some cases certain modules may not be listed by approval agencies or listing may be in process factory for latest listing status Listed S6012 7150 0559 0513 Approved COA 6246 6249 6250 ID AUBWFSPS Knight System and SWIFT are trademarks of International Inc and Windows are trademarks of Corporation is a registered of Duracell U S Inc Panasonic is registered trademark of Corporation by Honeywell Inc All rights Unauthorized use of document is strictly document is not intended be used for installation We try to keep our information up to and accurate We cannot all specific applications anticipate all requirements specifications are subject to without notice of origin Mexico Silent Knight Clintonville Road CT 06472 1610 B 10 18 Honeywell International Inc
