System Sensor 5151 EngSpec

Product Fixed Rate of Rise Thermal Detector and Engineering Specifications thermal detector shall be a System Sensor model number 5151 Detector shall a conventional fixed rate of rise thermal detector and shall connect with two wires to the fire control panel initiating device circuit IDC The detectors shall alarm at a fixed of 135 57.2 and have a rate of rise element rated at 15 8.3 per minute detectors shall have RTI rating for installation of V2 FAST or better detectors shall provide a test means whereby they will simulate an alarm condition and report condition to the control panel Such a test may be initiated at the detector itself by activating switch or initiated remotely on command from the control panel There are two test methods magnet or direct heat method detectors shall provide two LEDs to provide 360 visibility The LEDs are placed into steady illumination indicating that an alarm condition has been detected An output connection shall be provided in the base to connect an external remote alarm LED or relay base optional detectors shall be low profile ceiling mount wall mount and shall be plug in mounted into a base These detectors shall be constructed of off white UV resistant polymer and shall detachable from the mounting base to simplify installation service and maintenance Mounting wiring connections shall be made by means of SEMS screws The detector shall allow pre of the base and the head shall be a plug in type Mounting base shall be mounted on box which is at least 1.5 inches 3.81 cm deep Mounting base shall be available to to standard junction boxes Suitable boxes include 10.16 cm square box with and without plaster ring 10.16 cm octagonal box 8.89 cm octagonal box box Agency Standards CSFM 7270 Heat Detector 521 Heat Detectors for Fire Protective Signaling Systems 3210 Heat Detectors for Automatic Fire Alarm Signaling 2011
