System Sensor Carbon Monoxide DetectorsEngSpec

Product Carbon Monoxide Detector Specifications Specifications monoxide detector shall be a System Sensor model number CO1224T CO1224TR listed Underwriters Laboratories UL 2075 for Gas and Vapor Detectors and Sensors The detector be equipped with a sounder and a trouble relay The detector base shall be able to mount a single gang electrical box or direct surface mount to the wall or ceiling Wiring connections be made by means of SEMS screws The detector shall provide dual color LED indication blinks to indicate normal standby alarm or end of life When the sensor supervision is in a condition the detector shall send a trouble signal to the panel When the detector gives a or end of life signal the detector shall be replaced The detector shall provide a means to CO gas entry into the CO sensing cell The detector shall provide this with a test mode that CO gas from a test agent and alarms immediately upon sensing CO entry Specifications CO1224T CO1224TR Operating Voltage shall be 12 24 VDC The Audible Signal for the shall be 85 dB in alarm Standby Current shall be 20 mA Alarm Current shall be 40 mA mA test Alarm Contact Ratings shall be 0.5 A 30 VDC Trouble Contact Ratings shall be A 30 VDC Specifications CO1224T shall measure Length 5.1 in Width 3.3 in Height 1.3 in The CO1224T weight be approximately 7 oz The Operating Temperature Range shall be 32 to 104 0 to The detector Operating Humidity Range shall be 22 to 90 percent RH The CO1224T Terminals shall be 14 to 22 AWG CO1224TR shall measure Diameter 5.1 in Height 1.3 in The CO1224TR weight shall be 11 oz The Operating Temperature Range shall be 32 to 104 0 to 40 detector Operating Humidity Range shall be 22 to 90 percent RH The CO1224T Input shall be 14 to 22 AWG CO1224T CO1224TR shall be mounted to a single gang back box or surface mounted to a or ceiling Modes Normal standby mode the Green LED shall blink 1 time per minute In Alarm mode the Red shall blink in a temporal 4 pattern and the sounder will sound in a temporal 4 pattern Feature The System Sensor CO1224T CO1224TR carbon monoxide detector with can evaluate the functionality of the CO sensing cell using a canned test agent NOTE with local codes and the AHJ to determine whether or not a functional gas test is desired an installation Feature Pushing the Test Hush button will silence the sounder for 5 minutes except in mode Feature When the detector is in a trouble condition it will send a trouble signal to the Timer After the detector internal sensor has reached the end of its life a trouble will be sent to the panel This will indicate that it is time to replace the detector An carbon monoxide detector lifespan is approximately six years and the detector be replaced by the date marked on the inside of the product 2011
