System Sensor SW-ALERT Amber-Strobe EngSpec

Architects and Engineering Specification Advance Amber Lens Strobe amber lens strobe shall be System Sensor model number and shall be listed to for fire protective signaling The strobes shall be wired as a primary signaling notification and comply with the Americans with Disabilities Act requirements for visible signaling flashing at 1Hz over the strobe entire operating voltage range The strobe light shall consist a xenon flash tube and associated lens reflector system and shall operate between 32 and 120 amber lens strobes shall mount to a standard 4 4 1 back box 4 inch octagon back box or double gang back box A universal mounting plate shall be used for mounting The appliance circuit wiring shall terminate at the universal mounting plate amber lens strobe and the Sync module MDL3 accessory if used shall be powered from a notification appliance circuit output and shall operate on a nominal 12 or 24 volts includes fire panels with built in sync When used with the Sync Module MDL3 12 volt rated notification circuit outputs shall operate between 8.5 and 17.5 volts 24 volt rated notification appliance outputs shall operate between 16.5 to 33 volts If the notification appliances are not UL 9th edition with the corresponding panel or power supply being used then refer to the compatibility listing of the to determine maximum devices on a circuit amber lens strobe shall have field selectable candela settings of 15 15 75 30 75 95 110 115 135 177 185 listed under ANSI UL 1638 for reference equivalent candela for ANSI UL 1971 is 12 24 60 75 85 90 110 120 140 150 notification appliances shall be backward compatible
