Wheelock E70H & E90H speakers and strobes data sheet

Technical Data TD450018EN E70H E90H High Fidelity Speaker Strobes Wheelock E70H Wall and E90H Ceiling Speakers and Speaker are designed for high fidelity sound output for indoor With the widest frequency response range 300 to Hz in the industry the EH features leading intelligibility with clear voice messages and tone signaling ideal for emergency mass notification voice evacuation and fire alarm a sleek aesthetic appearance the Wheelock Series EH Fidelity Speakers and Speaker Strobes feature dual voltage VRMS capability and field selectable taps from 1 8 to 2 The low profile design incorporates a speaker mounting for faster and easier installation Each model has a built in level feature and an aesthetic two 2 screw grille cover visible signaling to meet the hearing impaired the EH Speaker models incorporate the Low Current draw RSS Strobes options for wall mount models include 1575 or Wheelock MCW multi candela strobe with field selectable candela of 15 30 75 110cd or the high intensity MCWH strobe with selectable 135 185cd mount models are available in Wheelock patented MCC ceiling strobe with field selectable intensities 15 30 75 95cd or the high intensity MCCH strobe with field 115 177cd strobe portion of all EH Speaker Strobes may be synchronized used in conjunction with the Wheelock DSM Sync Modules Power Supplies or other manufacturers panels the Wheelock Patented Sync Protocol Wheelock strobes offer an easy way to comply with ADA concerning photosensitive epilepsy EH Speaker Strobes are UL Listed for indoor use under Standard Signaling Devices for the Hearing Impaired and Standard 1480 Appliances and ULC listed under CAN ULC S526 Visual Signal Appliances Fire Alarm and under CAN ULC S541 Fire Alarm All inputs employ IN OUT wiring terminals fast installation using 12 to 18 AWG wiring options for the EH Speakers and Speaker Strobes are red and April 2020Supersedes March 2018 firealarmresources com Data TD450018EN April 2020 High Fidelity Sound Output Efficient design for high intelligibility at minimum wattage a frequency range of 300 to 8000 HZ 6 Field Selectable Settings Wall mount models are available with Field Selectable Candela of 15 30 75 110cd or 135 185cd Multi Candela models 1575cd Single Candela model Ceiling mount models are available with field selectable candela of 15 30 75 95cd or 115 177cd Multi candela models Field Selectable Taps 1 8 watt up to 2 watts 25 or 70 VRMS operation Easy to Install Low profile design incorporates speaker mounting plate for and easier installation Built in level adjustment feature and an aesthetic two 2 Quick installation with IN OUT screw terminals using 12 to grille cover AWG wires 4 square backbox prevents wire damage Strobe Synchronization Components Meet synchronizing standards with Wheelock DSM Sync PS Power Supplies or SAFEPATH products Compliance UL 1971 UL 1480 ULC S526 ULC S541 Low frequency requirements of UL 464 520 Hz to meet 520 Hz tone requirements for sleeping areas California State Fire Marshal CSFM ADA NFPA ANSI OSHA FCC Part 15 ICES CAUTIONS and WARNINGS are identified by the symbol warnings are printed in bold capital letters WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT VISIT WWW EATON COM MASSNOTIFICATION OR EATON FOR THE CURRENT INSTALLATION INSTRUCTIONS TO COMPLY WITH ANY OF THESE INSTRUCTIONS CAUTIONS OR COULD RESULT IN IMPROPER APPLICATION INSTALLATION OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR TO YOU AND OR OTHERS 1 E70H top and E90H bottom Speakers Front Side Views 2 E70H top and E90H bottom Speaker Strobes Front Side Views Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 E70H E90H High Fidelity Speakers Speaker StrobesEATON www eaton comfirealarmresources com Data TD450018EN April 2020 1 Maximum RMS Current Voltage VDC 2 UL Listed Models and Ratings Maximum RMS Current Series E70H Table 2 Maximum RMS Current Series E90H 24MCWH 24MCCH 241575W Speaker Speaker Speaker Strobe Speaker Strobe Reverberant dBA at 10 Feet b watts watts watts watts watts 3 Specification Ordering Information Candela w DSM or Power Supplies Lettering Lettering Lettering Lettering Q Q Q Q Q Q Q Q Q Q Q Q Q Q or white textured UV stabilized galvanneal steel Exceeds 94V 0 UL flammability rating Speaker 1.7 lbs 0.77 kg E70H Speaker Strobe 1.8 lbs 0.82kg E90H Speaker 1.5 lbs 0.68 kg E90H Speaker 1.6 lbs 0.73 kg Lexan 943A Speaker 5.13 W x 5.13 H x 0.43 E70H Speaker Strobe 5.13 W x 5.13 H x 2.56 E90H Speaker 7.27 x 0.43 D E90H Speaker Strobe 7.327 Diameter x 2.68 D 33.8 to 120.2 0 to 49 and maximum humidity of 93 backbox with extension ring prevents wire damage SBB for surface mount of E70H through 18 AWG VRMS 1971 ULC S526 are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules Power Supplies or SAFEPATH products using patented sync protocol Hz to 8000 Hz Range RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for 24v units For strobes the max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the maximum listed voltage 33v for 24v units For unfiltered ratings see installation instructions dBA ratings are based on testing under UL Standard 1480 1 8 watt tap is for private mode only Strobes 4 Specifications Material type Temperature Wire Connections indoor only Connections General voltage Output Rating Flash Rate Models E70H E90H High Fidelity Speakers Speaker StrobesEATON www eaton comfirealarmresources com Data TD450018EN April 2020 and Engineers Specifications speaker appliances shall be Wheelock Series E70H or E90H High Speakers and Speaker Strobe appliances or approved equals speakers shall be UL Listed under UL 1480 for Fire Protective and speakers equipped with strobes shall be listed under UL for Emergency Devices for the Hearing Impaired In addition strobes shall be certified to meet the requirements of FCC Part Class A speakers shall be designed for a field selectable input of either 25 70 VRMS with selectable power taps from 1 8 watt to 2 watts models shall have listed sound output of up to 87 dB at 10 feet a listed frequency response of 300 to 8000 Hz The
