Wheelock SAFEPATH brochure

mass notification system multi function supervised emergency communications messaging and background music system SP40S is an indoor supervised emergency system with 24 VDC battery backup The multi system also provides paging messaging and background for your facility It can be used stand alone or in combination a fire alarm system supplementing or replacing bells horns similar appliances used to sound the evacuation signal when an is initiated SAFEPATH provides live voice and pre recorded messaging to help direct people to safety SP40S integrates with fire alarm systems and provides full of building audible and visual notification appliances single channel system is capable of delivering 40 watts of high fidelity audio power and 2 amps of supervised 24 synchronized strobe power It comes standard with an on board voice messaging system with 8 standard messages a hand microphone power supply battery charger and numerous features combined with audio boosters and Wheelock speakers Eluxa LED3 and EH series the SP40S also meets NFPA 72 low tone requirements for sleeping areas is expandable to 5280 watts utilizing the SPB 80 4 80 and 4 amps of strobe power the SPB 160 160 watts or SPB 320 watts supervised audio power boosters All models are in 115 VAC or 220 VAC Approvals Compliance UL 864 UL 1711 UL 2017 code 4 UL code 3 and the low frequency requirements of UL 464 520 California State Fire Marshal CSFM New York City MEA Part 15 ADA compliant OSHA 1910.165 compliant System does not require reliability every two months or required spare parts inventory the building owner costly inspection fees Multi function system voice evacuation mass notification general per NFPA 72 supervised background music capabilities masking and low frequency tone requirements for sleeping applications Fully supervised 2 amps of supervised 24 VCD strobe power per Supervised NAC and audio circuits On board diagnostics reporting circuits Messaging Built in tones standard messages for different custom messages available alerts employees in all types of emergencies in various including corporate campuses educational facilities plants warehouses retail stores and healthcare facilities SAFEPATHfirealarmresources com evacuation 8 digitally pre recorded voice messages Live microphone override Selectable pre tones for messages Supervised NAC speaker and strobe circuits Easily interfaces with most existing phone system page port Automatically mutes BGM Frequency response 275 kHz Night ringer or security alert connection Capable of broadcasting from a supplied background music output Unique supervision method allows for full system supervision music source during background music Line level input for music source Frequency response 100 Hz KHz inputs and activation 2 Amps of 24 VDC supervised strobe power with built in sync protocol Power limited options and accessories Strobe output is selectable for control of Wheelock sync protocol Strobe terminals have pass through capability for Wheelock sync Any of the 8 messages can be dip switch selected to activate Microphone activation can be dip switch selected to activate non sync operation non sync operation Auxiliary activation remote microphone can be dip switch to activate strobes 24 VDC supervised and synchronized strobe power can be to meet the requirements of the installation via to optional Wheelock power boosters 40 watts of supervised audio power Speaker outputs 25V or 70.7V power limited supply and batteries 24 VDC 33AH max rechargeable battery back up power circuitry Batteries can be housed in the enclosure Up to two BAT 1212 volt 12 ampere hour batteries can fit in the enclosure Actual size required will depend on speaker and or strobe load are sold separately Boosters to provide additional supervised audio power for live voice pre recorded messages or music BGM SPB 160 160 Watt Supervised Audio Power Booster two 80 watt circuits SPB 80 4 80 Watt Supervised Audio Power Booster with 4 amps of Supervised and Synchronized 24 Strobe Power two 2 amp circuits SPB 320 320 watt Supervised Audio Power Booster four 80 watt circuits Splitters Speaker Audio Splitter SP4Z A B Provides for expansion of one zone to up to 2 zones of supervised speaker audio output in Class A Provides for expansion of one zone to up to 4 zones of supervised speaker audio output in Class B Control volume control SP SVC Supervised volume control for use with UL Listed Life Safety Applications Up to 35 watts of 70.7 volt audio power input Microphones Telephone Paging SPRM Remote Microphone for use with SP40S SPRM GP General Paging Microphone for use with SPB 80 4 SPB 160 and SPB 320 SP4 RMX Remote Microphone for use with SP40S Expansion Module SP4 APS Addressable Telephone Zone Paging Speaker Splitter SP4 TZC Addressable Telephone Zone Paging Controller SAFEPATHfirealarmresources com options and accessories Supply Wheelock POWERPATH PS 8 LP is a supervised remote power supply battery charger in a profile cabinet that is used for supervision and expanded power driving capability of fire alarm Appliance Circuits NAC The PS 8 LP is filtered and regulated and provides 8 amps of distributed across 4 outputs From installation to maintenance the incorporated advanced allow you to save equipment and labor costs Pull Station MPS non coded Manual Pull Stations are constructed of high quality die cast metal for long performance and may be mounted on a single gang backbox Available in either single or dual configurations for indoor or outdoor use with SPST contacts and terminal strip connections The open contact will close when the pull station is activated and is rated for 30 VDC 1 amp and 120 VAC 1 amp The contacts are gold plated to avoid the risk of corrosion Stations push stations NPS for manual activation of SAFEPATH systems are available in Blue Red White and Yellow Custom wording is available e g Severe Weather Medical Alert Power Down Gas Release for the Push Stations For a complete list of the wording available for printing the push stations please refer to the NPS specification sheet numbers and additional information can be found on Eaton product specification sheets is a registered trademark All other trademarks are property of their respective owners Eaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740Eaton com Lifesafetynotification 2021 EatonAll Rights ReservedPrinted in USAPublication No BR450015EN June 2021firealarmresources com
