Fike Cheetah Network A 1 07 01

Architect and Engineer Specification Network Listed S2203 Approved J I 3003101 10 2292 network card allows the Cheetah con panel to operate on an eight 8 panel manager network functions are limited to same panel regard of the zone number It is not possible to place a in or a release condi from any panel except the one connected to the system manager member network allows each panel to independently in the event that the network are damaged The manager panel only job is supervise for the presence of the member panels Technical Cheetah network uses zone function Zones 1 100 are common to all panels on the For these zones any input will cause acti of all outputs for the same zone regardless of panel the devices are connected to Zones and higher are local to each panel Inputs on zones will only operate outputs connected to same panel However regardless of zone num every state alarm trouble etc that occurs is by all panels on the network 10 2292 is installed on the Cheetah board as an card The 24V 33mA of power by each 10 2292 is supplied by the Chee connection Each 10 2292 requires two connec A RS 232 cable supplied with each network is used to connect to Cheetah RS 232 jack 2 network field connection is a RS 485 circuit which a maximum of 4000 feet between each Chee panel special RS 485 cable such as Belden is recommended S 10th Street P O Box 610 cid 127 Blue Springs Missouri 64013 0610 U S A cid 127 816 229 3405 cid 127 Fax 816 229 0314 cid 127 www fike com 2002 Issue page intentionally left blank Fike Corporation All rights reserved No previously 1162 are subject change without notice
