AFP 200 Door Backbox and Panel Assembly Clintonville Road Northford CT 06472 484 7161 Fax 203 484 7118 Backbox Dress Panel Assembly 50422 A1 04 30 2003 ECN 02 623 unpack the door backbox and dress panel and check for shipping damage The AFP 200 door backbox and dress should be assembled as shown in the drawing below Refer to the following page for backbox dimensions cabinet should be mounted in a clean dry vibration free area where extreme temperatures are not encountered The area be readily accessible with sufficient room to easily install and maintain the panel Locate the top of the cabinet five feet above the floor with the hinge mounting on the left For more information on installation of the AFP refer to the AFP 200 Analog Fire Panel Instruction Manual Notifier Document 15511 Panel 50422 Rev A1 04 30 03 Backbox Mounting Dimensions in cm in 36.83 cm 31.75 cm in cm cm in cm in cm in cm in cm in 0.635 cm 50422 Rev A1 04 30 03
