Notifier N-ANN-100 80 Character LCD Remote Fire Annunciator

File Preview
File Preview
Click below to download for free

Text Preview

N ANN 100 80 Character LCD Remote Fire Annunciator N ANN 100 annunciator is a backlit 80 character LCD fire that mimics the Fire Alarm Control Panel FACP dis It provides system status indicators for AC Power Alarm Trou Supervisory and Alarm Silenced conditions N ANN 100 and the FACP communicate over a two wire serial employing the ANN BUS communication format Con devices are powered via two additional wires by either the FACP or a remote UL listed filtered power supply N ANN 100 displays English language text of system point including device type zone independent point alarm or supervisory status as well as any custom alpha labels into the control panel It includes control switches for control of critical system functions A keyswitch prevents operation of the control switches to eight N ANN 100s may be connected to each ANN BUS of a No programming is required which saves time during system Listed to UL Standard 864 9th Edition Backlit 80 character LCD display 20 characters x 4 lines Mimics all display information from the host panel Control switches for Signal Silence System Acknowledge Reset Control switches can be independently enabled or disabled at the Drill Keyswitch enables disables control switches and mechanically annunciator enclosure Keyswitch can be enabled or disabled at the FACP Enclosure supervised for tamper System status LEDs for AC Power Alarm Trouble Supervisory Alarm Silence Local sounder can be enabled or disabled at the FACP N ANN 100 connects to the ANN BUS terminal on the FACP and minimal panel programming Displays device type identifiers individual point alarm trouble zone and custom alpha labels Time and date display field Surface mount or flush mount installation options Optional trim ring for a more finished look Can be remotely located up to 6,000 feet 1,800 m from the Backlight turns off during AC loss to conserve battery power but turn back on if an alarm condition occurs May be powered by 24 VDC from the host FACP or by remote supply requires 24 VDC Up to eight N ANN 100s can be connected on the ANN BUS and Indicators AC Power Alarm Trouble Supervisory Alarm Silenced Flush Mount Outside wall 12.25 x 11.5 x 0.875 31.1W 29.2H x 2.2D cm Inside wall 9.375 x 8.375 x 2 x 21.3H x 5.1D cm Surface Mount Including Trim Ring 12.25 x 11.5 3 x 29.2H x 2.2D cm Operating Voltage 24VDC Standby Current 20mA Alarm Current 25mA Wiring Distance Up to 6,000 ft max from FACP All connections are power limited and supervised For use indoors in a dry location Relative humidity 93 2 RH non condensing at 32 2 Ambient temperature 32 to 120 0 to 49 3 Listings and Approvals listings and approvals below apply to the ANN 100 In some certain modules may not be listed by certain approval agen or listing may be in process Consult the factory for the latest status S635 Information 80 character remote fire annunciator black Optional trim ring for surface mount applications black 1 22 2019 Page 1 of 2 Clintonville Road CT 06472 document is not intended to be used for installation purposes try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice and FireWarden are registered trademarks of Honeywell Inc by Honeywell International Inc All rights reserved Unauthorized of this document is strictly prohibited of Origin USA
