NFV 25 50DA Audio Panel Notifier FireVoice 25 50DA NFV 25 50DA is a compact Audio DA panel which is designed to interface the FireVoice 25 50 NFV 25 50 Series audio panels to audio in systems that require more than 25 watts NFV 25 50DA is offered in a self contained modular that includes a single channel 25 Watt 25 VRMS amplifier An optional 25 Watt 25 VRMS audio amplifier available to expand the NFV 25 50DA to 50 Watts provid dual 25 Watt speaker circuits or as a secondary backup NFV 25 50DA can be used to distribute voice evacuation throughout a facility The audio riser input provides gain control AGC which compensates for any signal loss due to circuit loading or cable length to delivery of a full output signal to the speakers For requiring 24 hour backup the built in power supply battery charger are able to charge up to 18 AH batteries to 25 NFV 25 50DA units can be connected to an NFV master unit If all units are equipped with the optional amplifier the total wattage can be 1300 watts options include a digital message generator module a factory recorded voice with field record and play capability up to five distinct messages Optional 70.7 conversion modules are available for applications 70.7 VRMS speakers technological enhancements set the NFV 25 Series apart from other voice panels The NFV 25 has full supervision in both active alarm and standby Independent power feeds to each amplifier that a short circuit in one amplifier will not shut down other Full output power 25 watts per amplifier is gener with the optional 70.7 VRMS transformer module during battery conditions Additionally modern integrated cir as opposed to transformer technology amplifies audio very low signal distortion applications include but are not limited to schools dormitories theaters restaurants places of motels hotels office buildings and factories 25 watts of 25 VRMS audio power expandable to 50 watts panel Automatic gain control AGC Optional 70.7 VRMS conversion module available for each primary AC power supply and secondary battery circuit Designed for maximum system flexibility and expansion Unobstructed module access and removable terminal for ease of service and maintenance Optional digital message generator module FC MGM factory prerecorded emergency evacuation message custom 60 second recorded message capacity Five Command Input Circuits C 20 Control Systems Field selectable message and field recording capability optional FC MGM RCA jack or mini audio input for connection to external audio devices Built in alert tone generators with steady slow whoop or chime tones Alert tone selection may be field programmed to conform ANSI S3.41 Audible Emergency Evacuation Signal Pattern per NFPA diagnostic LEDs include Power System Trouble Message Generator Trouble Tone Generator Trou Amplifier Fault and others Form C trouble relay allows FACP to monitor system while in active alarm state 35 mA Special Application auxiliary power output for modules and End of Line power supervision Optional local playback speaker for use with optional mes generator module Modules AUDIO AMPLIFIER MODULE Provides 25 watts of power at 25 VRMS and one fully and power limited speaker circuit that can be for Style Y Class B or Style Z Class A operation in the Distributed Audio Panel 1 13 10 Page 1 of 4 Two LEDs to indicate amplifier supervision Modules AUDIO AMPLIFIER MODULE Optional second audio amplifier can expand system power 50 watts providing dual 25 watt speaker circuits Can also be used as a backup amplifier TRANSFORMER MODULE 70.7 VRMS Converts 25 VRMS to 70.7 VRMS at full rated 25 watt out power MESSAGE GENERATOR MODULE Provides custom message recording capabilities and sys audio backup Custom messages may be recorded from audio sources to audio jack on FC MGM Built in tone generators provide tones before and after as well as backup on message failure LOCAL PLAYBACK SPEAKER Allows local review of digital messages no need to broad over system speakers The FC LPS is not intended for permanent installation REMOTE MICROPHONE MODULE Microphone module provides general paging capabilities speaker circuits When used with the NFV 25 50DA a FCMIM Microphone The VEC RM Module must be a FCMIM AC Power Supervised nonpower limited cir 2.0 Amp maximum 120 VAC 50 60 Hz Wire size 14 AWG 2.00 mm2 with 600 V insulation Power Battery Charging Circuit Maximum Circuit Normal Flat Charge 27.6 VDC 800 mA Battery Charger Capacity 18 Amp Hour cabinet maximum of two 18 Amp Hour batteries Nonpower supervised Supports lead acid batteries only Loss Relay Relay contact rating 2.0 amps 30 VDC 0.6 amps 30 VAC resistive Non supervised Input Circuits CMD1 CMD2 circuits are field programmable to activate amplifiers on polarity reversal or contact closure CMD3 CMD4 and are fixed to activate on contact closure only Power and supervised circuitry Normal Operating Voltage VDC 29 VDC Maximum Voltage 29 VDC Audio In on ACC AAM25 A second optional can be installed as a backup to the primary or expand speaker power to 50 watts Circuit on ACC AAM25 Power limited super circuitry Operation Circuit can be wired Style Y Class or Style Z Class A Normal Operating Voltage 25 VRMS 1 amp max and maximum load impedance of 25 Ohms VRMS 350 mA max with maximum load impedance 200 Ohms operation possible by plugging optional FC conversion module into P1 of audio amplifier Maxi total capacitance for each AAM 25 50 250 uF 2 of 4 DN 60048 b1 1 13 10 CMD Bus Supervised and power limited circuitry Operating Voltage 24 VDC regulated filtered Maxi Voltage 25.4 VDC Reverse Polarity Current 125 mA Maximum Load Resistance 200 ohms Application Power Aux Power Non Supervised Power limited circuitry Up to 35 mA 24 VDC special power is available for powering addressable mod and associated End of Line power supervision relays Trouble Relay Form C relay contact rating 2.0 30 VDC resistive 0.6 amps 30 VAC resistive Audio Inputs on optional FC MGM RCA Jack Input female connector Input Impedance 30 maximum Input Voltage 700 mVRMS maximum Current 1 mA maximum 700 mV Requires pream output Mates to an RCA phono 3mm diameter length 9mm shell diameter 3.5 mm PC Audio Jack female connector Input Impedance 150 Kohms Input Voltage 700 mVRMS maximum Input Cur 1 mA maximum 700 mV Requires preamplifier output optional Connects to VEC RM Remote Micro Module to provide remote microphone paging capabil Riser Magnetically isolated input utilizes signals up 70.7 VRMS with a frequency range of 400 Hz to 4 KHz Maximum input signal to the riser cannot exceed 25 VRMS a 20 watt speaker load per amplifier or 20 VRMS with a 25 speaker load per amplifier when background music is enabled Contact Input Non supervised non isolated trou input that can be used by chargers power supplies etc Closure Operation Current 1.2 mA maximum SPECIFICATIONS 0.174 0.44 cm high x 0.28 0.71 cm wide x 0.05 cm deep 26.0 66.04 cm high x 15.50 39.37 cm wide x 10.71 cm deep ring Outer measurement 21.62 54.92 cm high x 47.30 cm wide inner opening 18.63 47.31 cm x 15.63 39.69 cm wide with six holes for 8 32 and cutouts for hinges and Indicators INDICATORS Main Circuit Board Power On green AC Power green Active green System Trouble yellow Tone Generator Trouble yellow Battery Trouble yellow Charger Trouble yellow Ground Fau
