PF24V A ExitPoint Sounder Voice Messaging sounder ExitPoint Directional Sounder has an integral audio that produces a pulsating sound consisting of broad low mid and high range sounds The broadband noise it possible to determine the location of the sound are four pulse patterns that can be used to create an pathway out of a building and to mark perimeter exits addition to the broadband noise the sounder is capable of an alert message in the form of a recorded voice mes or other audible signals These messages will instruct the of what action to take as they approach the direc sounder and will allow them to react quickly and confi when activated Fifteen different combinations are available to instruct occupants that are nearing an exit a stairway up a stairway down or an of refuge The directional sounder also incorporates an disable feature for use in conjunction with a control or heat sensor directional sounder features a number of field selectable settings including high medium high medium low and Installation ease and pleasing aesthetics are achieved by low profile compact design and by the ability to flush mount a 4 x 4 x 2 back box directional sounders fitted in addition to normal evacuation sounders draw people to evacuation in both good and poor visibility The directional sounder be used in a wide range of building applications Trials have shown an improvement of up to 75 percent evacuation times in smoke and up to 35 percent without The 2007 Edition of NFPA 72 now provides installation maintenance guidelines on directional sounders Listed to UL 464 indoor applications only Five field selectable power settings Four field selectable routing evacuation patterns Constructed to be effective in unfamiliar surroundings or visibility Designed to work in open areas corridors or stairs Fifteen different language selections available Reduces evacuation times by as much as 75 percent Optional disable feature for use in conjunction with a control or heat sensor Low profile compact design SPECIFICATIONS Input Regulated 24 Volts Voltage Range 16 to 33 Volts Temperature 32 to 120 0 to 49 Setting High medium high medium medium low low SPECIFICATIONS Terminals 12 24 AWG Size 4 101 mm Size 4 7 8 127 mm Devices Tone Selection Position Position Setting Setting Output of Refuge Here Selection Position Setting 3 4 Sound Output Setting Guide Switch 1 Switch 2 Switch 3 06 17 2010 Page 1 of 2 Draw Measurements and Sound Output Guide DC RMS 1 2 Exit Exit Exit Exit Exit 1 Sound output measured in anechoic room at 10 feet 2 Sound output measured in a reverberant room at 10 feet Tone Guide tone sweep Mandarin English Cantonese English Mandarin Cantonese Mandarin English Korean English Portuguese English Russian English Polish Listings and Approvals product manual for lists of compatible UL Listed In some cases certain modules may not be listed by approval agencies or listing may be in process Con factory for latest listing status UL Listed S4011 ULC Listed S8971 FM Approved CSFM 7135 1653 175 MEA Approved 492 04 E Vol 2 Information ExitPoint Directional Sounder with Voice Messaging Same as PF24V but with ULC Canada Surface mount backbox skirt for PF24V and System Sensor are a trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited and document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 60245 B 06 17 2010
