XP6 R A Relay Control Module XP6 R six relay control module provides an fire alarm system with six Form C relays first module is addressed from 01 to 154 while the modules are automatically assigned to the next higher addresses Provisions are included for disabling a of three unused modules A single isolated set of relay contacts is provided for each module address is capable of being wired for either a normally open or operation The module allows the control to switch these contacts on command No supervision provided for the controlled circuit XP6 R module has panel controlled green LED indica The panel can cause the LEDs to blink latch on or latch Six addressable Form C relay contacts Removable 12 AWG 3.25 mm to 18 AWG 0.9 mm terminal blocks Status indicators for each point Unused addresses may be disabled Rotary address switches FlashScan or CLIP operation Mount one or two modules in a BB XP cabinet optional Mount up to six modules on a CHS 6 chassis in a CAB 3 CAB 4 Series EQ Series or BB 25 cabinet Mounting hardware included current 1.45 mA SLC current draw with all used if some addresses are disabled the current decreases current 32 mA assumes all six relays have been once and all six LEDs solid ON range 32 to 120 0 to 49 10 to 93 non condensing 6.8 17.27 cm high x 5.8 14.73 cm wide x 2.54 cm deep weight 1.1 lb 0.5 kg including packaging options CHS 6 chassis BB 25 cabinet BB XP CAB 3 Series see DN 3549 cabinet CAB 4 Series DN 6857 cabinet or EQ Series see DN 60229 cabi gauge 12 AWG 3.25 mm to 18 AWG 0.9 mm SLC wiring resistance 40 or 50 ohms panel current 30 mA relay pulse 15.6 ms pulse duration under panel control contact ratings 30 VDC 70.7 VAC A 115 Devices ratings 3.0 A 30 VDC maximum resistive non coded 2.0 A 30 VDC maximum resistive coded 1.0 A 30 VDC maximum inductive L R 2 ms coded 0.5 A 30 VDC maximum inductive L R 5 ms coded 0.9 A 110 VDC maximum resistive non coded 0.9 A 125 VAC maximum resistive non coded 0.7 A 70.7 VAC maximum inductive PF 0.35 non 0.3 A 125 VAC maximum inductive PF 0.35 non 1.5 A 25 VAC maximum inductive PF 0.35 non 2.0 A 25 VAC maximum inductive PF 0.35 non Listings and Approvals listings and approvals apply to the modules specified this document In some cases certain modules or applica may not be listed by certain approval agencies or list may be in process Consult factory for latest listing status UL Listed S635 ULC Listed S635 XP6 RA MEA Listed 368 01 E CSFM 7300 0028 0219 Maryland State Fire Marshall Permit 2099 FM Approved Light Protective Signaling Only 4 12 2016 Page 1 of 2 Line Information Six relay control module Same as above with ULC Listing Optional cabinet for one or two modules Dimen DOOR 9.234 23.454 cm wide 9.484 24.089 cm hinges x 12.218 31.0337 cm high x 0.672 cm deep BACKBOX 9.0 22.860 cm wide 9.25 cm including hinges x 12.0 30.480 cm high x 6.985 cm CHASSIS installed 7.150 18.161 cm overall x 7.312 18.5725 cm high interior overall x 5.4762 cm deep overall Optional cabinet for up to six modules mounted on chassis below Dimensions DOOR 24.0 60.96 wide x 12.632 32.0852 cm high x 1.25 3.175 cm hinged at bottom BACKBOX 24.0 60.96 cm wide x 31.877 cm high x 5.218 13.2537 cm deep Chassis mounts up to six modules in a CAB 3 see DN 3549 CAB 4 Series see DN 6857 BB 25 or EQ Series see DN 60229 cabinet and FlashScan are registered Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited of Honeywell document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 2 of 2 DN 6926 A2 4 12 2016
