Potter PAD100-4DB 6DB 4 6 Addressable Detector Base

Features Terminals Marked with polarity to assist with installation Duplicate terminals for in and out SLC wiring Terminals accept 22 to 12 AWG wire sizes Installs on single gang double gang octagon or 4 square box Locking tab prevents unauthorized detector removal product includes 5 year warranty potter paD100 6DB and paD100 4DB detector bases are used install potter addressable smoke and heat detectors The paD100 will mount on a single gang double gang octagon or 4 square box Specifications Options Single gang double gang octagon and 4 Guage box Type to 12 AWG 6.3 in 166 mm 0.72 in 18 mm 3.07 oz plastic Weight PAD100 6DB and PAD100 4DB are low profile surface mount used with potter addressable detectors The base uses screw terminals that accept wire ranging from 22 to 14 AWG When on recessed electrical boxes the paD100 6DB is wide enough completely cover the back box and the immediate surrounding area base is equipped with a locking tab to deter unauthorized removal the attached detector page 1 OF 2 REV C 12 18PRINTED IN USAPotter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comPAD100 4DB 6DB4 Addressable Detector Basefirealarmresources com Feature PAD100 6DB and PAD100 4DB include a locking feature that removal of the detector without using a tool To eliminate this feature break off the locking tab refer to Figure and then install the detector 1 Diagram 3 FaCp SLC Detector Base Detector Base off tab gray in image to disable feature To remove the detector from the base when the locking feature has enabled insert a small screw driver into the slot on the base to the plastic tab while simultaneously turning the detector head 2 Information Sensor Base Sensor Base No small screwdriver slot to remove from base page 2 OF 2 REV C 12 18PRINTED IN USAPotter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comPAD100 4DB 6DB4 Addressable Detector Basefirealarmresources com
