Siemens SP4-RMX Remote Microphone Expansion Module, Data Sheet

Data Microphone Expansion Module Capable of connecting up to 3 three remote AND ENGINEER SPECIFICATIONS stations Model SPRM When connected to either Model SP40S two 2 Model SP4 RMX units can be together providing up to six 6 remote microphones Model SP4 RMX connection to either Model SP40S the entire system benefits from the microphone capability Provides an auxiliary input for connection of an external repeater for additional messages Can accept a line level input for broadcasting of other information Up to nine 9 logical zones A logical zone is an individual or fixed user selected group covering five 5 zones max Can be connected to audio boosters for general non alarm paging Model SPRM GP Multiple on board diagnostics with three 3 status conditions Alarm and Trouble OSHA 1910.165 ADA and UFC 04 021 01 2002 Compliant UL 864 9th Edition Listed ULC Listed CSFM NYC Fire Department Approved Overview remote microphone expansion module SP4 RMX provides for an auxiliary input for of an external VoiceLink message repeater additional messages SP4 RMX expands one 1 remote microphone SPRM from either the Model SP40S to three 3 microphones 2 Model SP4 RMX modules can be cascaded providing up to six 6 remote microphones either Model SP40S SP4 RMX shall be a supervised outboard module for use with the SAFEPATH Communications Voice Evacuation Model SP4 RMX shall be used to expand up to 3 optional supervised Remote Microphone SPRM modules 2 Model SP4 RMX Remote Microphone Expansion can be connected to either the Model SP40S and have the capability of providing the Model SP40S up to six 6 system wide Call Remote Model SPRM modules Model SP4 RMX can be connected to audio boosters for general non paging with use of Model SPRM GP SP4 RMX can be programmed to provide either override for each first out Model SPRM The first out procedure allows the active SPRM to complete its communication before Model SPRM can be used All output circuitry be power limited Remote Microphone Expansion Module 3753 Industry Inc Technologies Division Data Power W x H x D filtered regulated 22 Wire Gauge AWG x 13 x 2 cm x 33 cm x 5 1 cm for Ordering Remote Microphone Expansion Module continued on board diagnostic light emitting diode indicators shall be provided All wiring shall be to the module using quick connect wiring terminals capable of accepting 22 AWG wiring Model SP4 RMX can support Model SPRM at a range up to 2,000 feet meters following table gives details on microphone and levels when Model SP4 RMX is used either Model SP40S SP40 on board microphone SP4 RMX remote microphones 1 2 3 priority or first out SP4 RMX auxiliary input only SP40 standard message 1 SP40 standard message 2 SP40 standard message 3 SP40 standard message 4 SP40 standard message 5 SP40 standard message 6 SP40 standard message 7 SP40 standard message 8 This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2012 Issue 0
