NOTICE This manual shall be left with the owner user of this equipment product is intended for use in ordinary indoor locations 1 DETECTOR OPERATION MODES AND MAINTENANCE INSTRUCTIONS Monoxide Detector Specifications Voltage Standby Current Alarm Current Contact Ratings Contact Ratings Signal temp 4 tone Start up Capacitance mA mA 75 mA test VDC 0.5 A VDC 0.5 A dBA min in alarm at 10ft uF VDC VDC VDC Round shape allows for mounting in aesthetically demanding areas Optional CO detector replacement plate for previously installed detectors DESCRIPTION Listed to standard 2075 Six wire system monitored Local sounder Low current draw Alarm relay Form C Trouble relay Form A Dual LED Test Hush button SEMS wiring terminals Mount to single gang electrical box or surface mount to wall or ceiling Optional drywall anchors included 1 ALARM LOCATION DIAGRAM MONOXIDE SMOKE ALARM FOR MULTI LEVEL RESIDENCE Ohio Avenue St Charles Illinois 60174 FAX 630 377 6583 Specifications Temperature Range Humidity Range Gauge Acceptance to 40 32 to 104 90 RH oz AWG LED LED 1 minute 4 pattern 4 pattern 4 pattern 4 pattern 1 second 4 pattern CO is sprayed Test of Life Trouble Loss Fault 1 minute Test Will send alarm signal to panel feature Alarm Silence If required the audible alarm can be silenced 5 minutes by pushing the button marked The red alarm light continue to flash in temp 4 pattern If carbon monoxide is still present the 5 minute hush period the audible alarm will sound The hush facility not operate at levels above 350 ppm parts per million carbon monoxide Alarm Silence Alarm will automatically silence after about 20 sec of alarm from spraying canned CO into the detector Alarm Reset Alarm resets after CO has cleared from the sensor feature When the sensor supervision is in a trouble condition e g as a sensor that has been tampered with or the cell itself has prema dried out due to environmental conditions etc the detector will send trouble signal to the panel The detector must then be replaced The green turns off and the red LED blinks every minute when the detector is in of Life Timer feature When the detector has reached the end of its life trouble contact will open This indicates that the CO sensor inside the has passed the end of its life and must be replaced This detector is approximately ten years from the date of manufacture The green turns off when the detector is in trouble Periodically check the sticker located under the detector cover The detector must be replaced by date Refer to Detector Replacement on page 3 UL 2075 it is mandatory that a trouble signal be sent to the panel CO cell trouble or cell end of life Refer to Figure 4 for wiring of the relay GUIDELINES Detector should be at least 12 inches from any wall Detector should be at least as high as a light switch and at least six from the ceiling Do not install in any environment that does not comply with the detec environmental specifications Install in accordance with NFPA 720 Standard for the Installation of Monoxide CO Detection and Warning Equipment As of 2009 NFPA 720 defines standards for both commercial and resi installations of CO detectors If the installation can be interpreted a commercial application consult the section of NFPA 720 that out commercial applications For example Chapter 5.5.5.3.1 states that carbon monoxide detectors be installed in accordance with manufacturers published instruc in the following locations On the ceiling in the same room as permanently installed fuel burn appliances building Centrally located on every habitable level and in every HVAC zone of If the installation can be interpreted as residential consult the section of 720 that outlines residential applications For example chapter 9.4.1.1 states that carbon monoxide alarms or shall be installed as follows Outside each separate dwelling unit sleeping area in the immediate of the bedrooms On every level of a dwelling unit including basements Other locations where required by applicable laws codes or standards CO1224T CO1224TR can be ceiling mounted or wall mounted To a single gang box Direct mount to ceiling or to wall using drywall fasteners 2 MOUNTING OF DETECTOR INSTALLATION GUIDELINES wiring must be installed in compliance with the NFPA 70 National Electrical applicable state and local codes and any special requirements of the local Having Jurisdiction AHJ wire gauges should be used The conductors used to connect carbon detectors to the alarm control panel and accessory devices should color coded to reduce the likelihood of wiring errors Improper connections prevent a system from responding properly in the event of a CO screw terminals in the mounting base will accept 14 22 gauge wire Wire are made by stripping approximately 1 of insulation from the of the feed wire inserting it into the proper base terminal and tightening screw to secure the wire in place Do not put wires more than 2 gauge under the same clamping plate This product does not have a local audible trouble signal and fail without supervision if trouble loop remains unconnected Gas detectors on a zone that is bypassed may not signal a trouble Do not bypass zones used for gas detectors diagrams located on page 4 Figure 4 power from alarm control unit or initiating device circuits before in detectors Using a small flat head screw driver push in the small tab located on the of the detector Once the snap is loosened lift the bottom end the cover up and unhinge the top to remove the cover Wire the detector base screw terminals per Figure 5 Screw the base of the detector onto a single gang electrical box or to the of the wall or ceiling Use the hardware included in the packaging mounting with the System Sensor replacement plate model CO PLATE Hold replacement plate over desired mounting area Use hook feature to hold CO1224T onto the replacement plate Mount detector and plate together using hardware provided with the Hinge the top portion of the cover onto the base with the cover at a 45 angle fit the hinges into the slots of the base Push the unhinged bottom portion of the cover down until it snaps into place After all detectors have been installed apply power to the alarm control unit Test each detector as described in Testing Notify the proper authorities that the system is in operation dust particles can enter the detector System Sensor recommends the of detectors after construction or any other dust producing activ Carbon monoxide detectors are not to be used with detector guards unless combination has been evaluated and found suitable for that purpose must be tested after installation Before testing notify the proper authorities to avoid any nuisance proper wiring and power is applied After power up allow 80 seconds the detector to stabilize before testing the CO1224T CO1224TR detector as follows A test button is located on the detector housing See Figure 4 Use the tip of your finger to press and hold the test button for 1 4 If the sounder beeps twice in the Temporal 4 tone and the LED light up detector is operational The detector now enters Realtest speed up test mode indicated by a blinking green LED See Functional Gas Test section for ins
