MA 1 Omni Directional Loudspeaker Power Speaker Array UL1480A listed 1.13 mile radius STI 0.91 out of 1.0 143 dB SPL peak acoustic output Hazardous Location Certified Class I Division 2 CID2 A B C and D outdoor wet listed HyperSpike MA 1 is a customizable omni directional high speaker array that broadcasts live and pre recorded voice and tones over a 4 square mile area Leading the in voice intelligibility the MA 1 speaker design achieves an STI of 0.91 1.0 ensuring commands are clearly heard in high noise environments The battle tested MA 1 comes with waterproof and UV resistant enclosure ensuring in harsh environments 5 3 2 and 1 sided configurations available Voltage 41 VRMS Multi Channel 90 VRMS Single Channel Power 320 W max per side continuous alert tone Response 125 Hz 8 kHz Width 120 360 12.8 DIA x 26.2 H 5S 50 lbs 21.8 kg 3S 31 lbs 14.1 kg 2S 24 lbs 10.1 kg 1S 16 lbs 7.3 kg CID2 Groups A B C and D UL1480A Listed CSA C22.2 No 205 CAN CSA C22.2 No 213 15 ANSI ISA 12.12.01 2015 Rating per Multi Channel per 20 to 60 and Engineer Specifications High Power Speaker Array shall be a HyperSpike model 90 80 providing alarm tone pre recorded or voice announcements at dB measured at 1 meter from the source The emitter shall be a sided unit weighing more than 50 lbs 21.8 kg with one 1 2 outside diameter OD pipe and pedestal pole or wall mounting hardware emitter shall be able to transmit an 80 dB LAeq audible signal up to 1,969 feet and operate at a power of 320 W to W Equipment shall be suitable for indoor or outdoor wet locations and approvals shall include UL1480A listing with I Division 2 Groups A B C and D Hazardous Location Certification or Non Hazardous locations only Rev A Electronics USSI 4868 East Park 30 Drive Columbia City IN 46725 8861 1 of 3 Omni Directional Loudspeaker N A Not certified 90162A only L 1480A and Class I Division 2 certified CODE 02 Tan 04 Gray 801 5 sided 802 3 sided 803 2 sided 804 1 sided 90105A MA 1 Single Channel 90223A MA 1 Multi Channel 90162A MA 1 Connectorized campus overlay using two MA 1 5 sided emitters Heavy Duty with bag Mounting Kit HS Series Emitter Pole Mounting Kit Emitter Wall Mount Mounting Kit 10 Foot Roof Mount Mounting Kit Emitter Ceiling Mount Amplifier Crown 4002 Xti Pod Optimizer Software MA Series individual replacement service kit Connectorized Cable length and vary Tan Speaker Cover Gray Speaker Cover MA 1 comes standard with a mounting adaptor that a 2 diameter pole and has 2 3 8 screws to lock unit in place Routing Single and Multi Channel Systems single and multi channel MA 1 systems come with a long flexible conduit and 11 foot 14 AWG The connection at the end of the conduit requires installer supplied junction box with a rating suitable the installation environment of the box Routing Connectorized Systems connectorized MA 1 systems have a four pin that provides audio to the speaker from the Included with the unit is a speaker cable used connect the unit to a customer supplied amplifier or optional HyperSpike amplifier PROVIDED 3R OR BETTER JUNCTION FOR OUTDOOR INSTALLATIONS NEMA 1 BOX FOR INDOOR PROVIDED SYSTEM WIRING LOOP IF IN WET CONNECTIONS JUNCTION BOX AMPLIFIER AND CIRCUIT A Channel 1 B Channel 1 C N A D N A Rev A Electronics USSI 4868 East Park 30 Drive Columbia City IN 46725 8861 2 of 3 Omni Directional Loudspeaker Single and Multi Channel Systems single channel MA 1 has 14 AWG leads coming out of the speaker as depicted below The red black pair is used for to the customer supplied amplifier or the optional HyperSpike amplifier kit and the blue yellow pair is used for a circuit multi channel MA 1 has a red and black twisted pair of 18 AWG wires coming from each face of the speaker The total of pairs coming out of the speaker will depend on the number of faces populated Each pair has an impedance of 6 and a power rating of up to 320 watts These leads may be attached to a customer supplied amplifier or the optional amplifier kit AMPLIFIER AMPLIFIER Rev A Electronics USSI 4868 East Park 30 Drive Columbia City IN 46725 8861 3 of 3
