MA Micro Omni Directional Loudspeaker Medium Power Speaker Array Hazardous Location Certified Class I Division 2 CID2 STI 0.84 1.0 0.4 mile radius UL1480A listed 134 dB SPL peak acoustic output A B C and D outdoor wet listed Suitable for indoor or outdoor applications HyperSpike MA Micro is a lightweight 360 power speaker array that broadcasts live and voice commands and tones over a half radius Leading the industry in voice intelligibility MA Micro speaker design achieves an exceptional of 0.84 1.0 ensuring commands are clearly and heard even in high noise environments battle tested MA Micro comes with a waterproof UV enclosure ensuring durability harsh Voltage Rating Response Width 41 VRMS Up to 500 W continuous 4 ohms 125 Hz 8 kHz 360 omni directional 20 lbs 9.1 kg 12.8 DIA x 8.0 H CID2 Groups A B C and D UL1480A Listed CSA C22.2 No 205 CAN CSA C22.2 No 213 15 ANSI ISA 12.12.01 2015 20 to 60 CID2 MA Micro 90145A 801 02 L 90145A 801 04 L MA Micro 90145A 801 02 90145A 801 04 90145A 802 02 90145A 802 04 92010A 801 90209A 802 10 Leads 10 Leads 10 Leads 10 Leads Connector Connector Tripod Heavy Duty with bag Mounting Kit HS Series Emitter Pole Mount Mounting Kit 10 Foot Roof Mount 90209A 804 74014A SK15 Mounting Kit Emitter Ceiling Mount ECC 90172A 805 90202A 803 90100A 801 42155A XXX Standalone Amplifier Crown 4002 Xti Amplification Pod Audio Optimizer Software Connectorized Cable length and gauge vary 70V Constant Voltage Transformer 90179A 801 and Engineer Specifications Medium Power Speaker Array shall be a HyperSpike model 90145A 80 providing alarm tone pre recorded or live announcements at dB measured at 1 meter from the source The emitter shall be a 5 sided unit weighing no more 20 lbs 9.1 kg with one 1 2 outside diameter OD pipe and pedestal pole or wall mounting hardware The emitter be able to transmit a 360 omnidirectional audible signal up to 0.5 square mile and operate at a power of 500 W shall be suitable for indoor or outdoor wet locations and approvals shall include UL1480A listing with Class I 2 Groups A B C and D Hazardous Location Certification or Non Hazardous locations only Rev A Electronics USSI 4868 East Park 30 Drive Columbia City IN 46725 8861 1 of 2 Omni Directional Loudspeaker MA Micro comes standard with a mast mount and intended to be pole mounted or suspended from this The unit can be rigidly mounted or hung sound modeling services and EASE EASE Evac gll are available Leaded Systems MA Micro system comes with a 10 foot long flexible conduit and 11 foot 14 AWG lead The connection at the end of conduit requires an installer supplied junction box with a rating suitable for the installation environment of the box MA Micro has 14 AWG leads coming out of the speaker as depicted below The red black pair is used for attaching to customer supplied amplifier or an optional HyperSpike amplifier Connectorized Systems connectorized MA Micro system has a four pin connector that provides audio to the speaker from the amplifier connectorized MA Micro has a four pin connector Included with the unit is a speaker cable used to connect the unit to customer supplied amplifier or an optional HyperSpike amplifier PROVIDED 3R OR BETTER JUNCTION FOR OUTDOOR INSTALLATIONS NEMA 1 BOX FOR INDOOR PROVIDED SYSTEM WIRING LOOP IF IN WET CONNECTIONS JUNCTION BOX AMPLIFIER AND CIRCUIT A Channel 1 B Channel 1 C N A D N A Rev A Electronics USSI 4868 East Park 30 Drive Columbia City IN 46725 8861 2 of 2
